Wiring Diagram VW PASSAT 2001 - Dash panel insert - diagnosis interface for data bus - self-diagnosis connection



Wiring Diagram VW PASSAT 2001 - Dash panel insert - diagnosis interface for data bus - self-diagnosis connection https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
J...Engine control unit
J285Control unit with display in dash panel insert
J533Diagnosis interface for data bus, in dash panel insert
T1616-pin connector, near handbrake lever, self-diagnosis connection
T32a32-pin connector, blue, on dash panel insert
T32b32-pin connector, green, on dash panel insert
   32 Earth point, behind dash panel, left
   81 Earth connection -1-, in dash panel wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
   A121 Connection (high bus), in dash panel wiring harness
   A122 Connection (low bus), in dash panel wiring harness
*For vehicles with a tachograph only

Wiring Diagram VW PASSAT 2001 - Control unit for ABS - steering angle sender sensor - engine control unit



Wiring Diagram VW PASSAT 2001 - Control unit for ABS - steering angle sender sensor - engine control unit https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G85Steering angle sender, on steering column
J104Control unit for ABS with EDL, in front right footwell
J220Motronic control unit, in protective housing for control units, left in engine compartment
J361Simos control unit, in protective housing for control units, left in engine compartment
T10n10-pin connector, orange, coupling station left A-pillar
T15s15-pin connector, red, on protective housing for control units, left in engine compartment
T3131-pin connector
T8080-pin connector
T8888-pin connector
T121121-pin connector
   A121 Connection (high bus), in dash panel wiring harness
   A122 Connection (low bus), in dash panel wiring harness

Wiring Diagram VW PASSAT 2001 - Diesel direct injection control unit - airbag control unit - automatic gearbox control unit



Wiring Diagram VW PASSAT 2001 - Diesel direct injection control unit - airbag control unit - automatic gearbox control unit https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J217Automatic gearbox control unt
J234Airbag control unit, behind lower console
J248Diesel direct injection system control unit
T10p10-pin connector, yellow, coupling station right A-pillar
T15m15-pin connector, brown, coupling station right A-pillar
T15s15-pin connector, red, on protective housing for control units, left in engine compartment
T5252-pin connector
T68a68-pin connector
T7575-pin connector
T8080-pin connector
T8888-pin connector
T121121-pin connector
   A121 Connection (high bus), in dash panel wiring harness
   A122 Connection (low bus), in dash panel wiring harness
