| F4 | Reversing light switch |
| M6 | Turn signal bulb, rear left |
| M16 | Reversing light bulb, left |
| M21 | Brake and tail light bulb, left |
| S223 | Fuse in fuse holder |
| T2 | 2-pin connector, on left tail light |
| T4 | 4-pin connector, on left tail light |
| T6a | 6-pin connector, on left tail light |
| T10a | 10-pin connector, brown, coupling station left A-pillar |
| 57 | Earth point, left rear pillar |
| 63 | Earth point, left tail light bulb holder |
| 87 | Earth connection -2-, in rear wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| E23 | Front and rear fog light switch |
| F216 | Rear fog light cut-out, contact switch |
| L46 | Rear fog light bulb, left |
| L47 | Rear fog light bulb, right |
| S235 | Fuse in fuse holder |
| T1 | Single connector, near left tail light |
| T6a | 6-pin connector, on left tail light |
| T6b | 6-pin connector, on right tail light |
| T6c | 6-pin connector, blue, coupling station left A-pillar |
| T10a | 10-pin connector, brown, coupling station left A-pillar |
| T13 | 13-pin connector, on trailer towing socket |
| U10 | Trailer socket |
| 57 | Earth point, left rear pillar |
| 238 | Earth connection -1-, in interior wiring harness |
| 500 | Screw connection -1- (30), on relay plate |
| A52 | Positive connection -2- (30), in dash panel wiring harness |
| W4 | Connection -1- (rear fog light), in rear wiring harness |
| W25 | Connection -2- (rear fog light), in rear wiring harness |
| F | Brake light switch |
| M8 | Turn signal bulb, rear right |
| M17 | Reversing light bulb, right |
| M22 | Brake and tail light bulb, right |
| S22 | Fuse in relay plate fuse box |
| T4a | 4-pin connector, on right tail light |
| T6b | 6-pin connector, on right tail light |
| T10a | 10-pin connector, brown, coupling station left A-pillar |
| 64 | Earth point, right tail light bulb holder |
| 75 | Earth point, rear pillar, right |
| 197 | Earth connection -4-, in rear wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| W1 | Positive (+) connection (54), in rear wiring harness |
| E3 | Hazard warning light switch |
| J1 | Turn signal relay |
| J285 | Control unit with display in dash panel insert |
| K6 | Hazard warning light system warning lamp |
| K18 | Trailer operation warning lamp |
| S239 | Fuse in fuse holder |
| T7a | 7-pin connector, on chamber 4 of hazard warning light switch (on vehicles not fitted with tow bar, the hazard warning light switch illumination is connected here) |
| T32a | 32-pin connector, blue, on dash panel insert |
| 32 | Earth point, behind dash panel, left |
| 81 | Earth connection -1-, in dash panel wiring harness |
