VW PASSAT CC 2010 – Panoramic tilting sunroof . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW PASSAT CC
  4. >VW PASSAT CC 2010
  5. >VW PASSAT CC 2010 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW PASSAT CC 2010 - Button 1 for tilting roof - Onboard supply control unit - Control unit for tilting sunroof - Tilting sunroof motor



Wiring Diagram VW PASSAT CC 2010 - Button 1 for tilting roof - Onboard supply control unit - Control unit for tilting sunroof - Tilting sunroof motor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E582 Button 1 for tilting roof
J519 Onboard supply control unit
J533 Data bus diagnostic interface
J878 Control unit for tilting sunroof
SC33 Fuse 33 on fuse holder C
T5ag 5-pin connector
T12i 12-pin connector
T16m 16-pin connector
T20e 20-pin connector
T52b 52-pin connector
V431 Tilting sunroof motor
  278 Earth connection 4, in interior wiring harness
  689 Earth point, at front, central in roof
  B130 Connection (sliding sunroof), in interior wiring harness
  B340 Connection 1 (58d), in main wiring harness
  B341 Connection 2 (58d), in main wiring harness
  B698 Connection 3 (LIN bus) in main wiring harness
*Up to March 2011
*2From March 2011
*3Up to March 2012
*4From March 2012
