VW PASSAT CC 2010 – Entry and start authorisation . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW PASSAT CC 2010 - Driver door exterior handle central locking button - Front passenger door exterior handle central locking button - Driver door exterior handle contact sensor - Front passenger door exterior handle contact sensor - Convenience system central control unit - Driver side aerial for entry and start system - Passenger side aerial for entry and start system

E369	Driver door exterior handle central locking button
E370	Front passenger door exterior handle central locking button
G415	Driver door exterior handle contact sensor
G416	Front passenger door exterior handle contact sensor
J393	Convenience system central control unit
R134	Driver side aerial for entry and start system
R135	Passenger side aerial for entry and start system
SC36	Fuse 36 on fuse holder C
T4ar	4-pin connector
T4cj	4-pin connector
T18a	18-pin connector
T18c	18-pin connector
T28	28-pin connector
T28c	28-pin connector
373	Earth connection 8, in main wiring harness
398	Earth connection 33, in main wiring harness
638	Earth point, on right A-pillar
639	Earth point, left A-pillar
647	Earth point 3, on bulkhead
B333	Positive connection 19 (30a) in main wiring harness
*	From March 2011
*2	Up to March 2011

J393	Convenience system central control unit
R136	Rear bumper aerial for entry and start system
R137	Luggage compartment aerial for entry and start system
R138	Interior aerial 1 for entry and start system
T2s	2-pin connector
T2u	2-pin connector
T2w	2-pin connector
T18c	18-pin connector

J393	Convenience system central control unit
J533	Data bus diagnostic interface
R139	Interior aerial 2 for entry and start system
R154	Aerial 3 in interior for access and start authorisation
T2gk	2-pin connector
T2x	2-pin connector
T18a	18-pin connector
T18c	18-pin connector
T20e	20-pin connector
B371	Connection 1 (aerial), in main wiring harness
B397	Connection 1 (convenience CAN bus, high), in main wiring harness
B406	Connection 1 (convenience CAN bus, low), in main wiring harness

J519	Onboard supply control unit
J942	Control unit for terminal control and engine start
SC16	Fuse 16 on fuse holder C
SC37	Fuse 37 on fuse holder C
T32g	32-pin connector
T52b	52-pin connector
T52c	52-pin connector
A66	Connection (30a, CL/ATA/IR), in dash panel wiring harness
B397	Connection 1 (convenience CAN bus, high), in main wiring harness
B406	Connection 1 (convenience CAN bus, low), in main wiring harness
B616	Positive connection 12 (30a), in interior wiring harness
*	Only models with starter button

D1	Immobilizer reading unit
D9	Electronic ignition lock
J519	Onboard supply control unit
J764	Control unit for electronic steering column lock
J942	Control unit for terminal control and engine start
N376	Ignition key withdrawal lock solenoid
T10k	10-pin connector
T16f	16-pin connector
T32g	32-pin connector
T52b	52-pin connector
T52c	52-pin connector
B259	Connection (start/stop signal), in interior wiring harness
B340	Connection 1 (58d), in main wiring harness
B341	Connection 2 (58d), in main wiring harness
S24	Positive connection (30) 3, in central locking wiring harness
*	Only models with starter button

EX23	Switch module 1 in centre console
E378	Starter button
J527	Steering column electronics control unit
J623	Engine control unit
J942	Control unit for terminal control and engine start
L76	Button illumination bulb
T16o	16-pin connector
T26h	26-pin connector
T32g	32-pin connector
T94	94-pin connector
396	Earth connection 31, in main wiring harness
400	Earth connection 35, in main wiring harness
639	Earth point, left A-pillar
687	Earth point 1, on centre tunnel
*	Only models with starter button
*2	Only models with 1.8l Total Flex engine
*3	Only models with 2.0l Total Flex engine
*4	Only models with 6-cylinder engine
