СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS) для Dodge Stratus R/T 2005

Электросхема антиблокировочной тормозной системы АБС (ABS) для Dodge Stratus RT 2005 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема антиблокировочной тормозной системы АБС (ABS) для Dodge Stratus R/T 2005 - Список элементов:

  • (behind right headlight) g1
  • (pin 22-29 not used)
  • (under left side of dash, near center console) data link connector
  • (w/ tcl only)
  • Abs ecu (at right rear corner of engine compartment)
  • Abs indicator
  • Abs solenoid valve
  • C101
  • C102
  • C308
  • C312
  • Combination meter
  • Connector lock switch
  • Cruise control, transmissions & exterior lights systems
  • Engine compartment relay box (left side of engine compt, in front of wheel housing)
  • Fuse 11 15a
  • Fuse 13 7.5a
  • Fuse 23 7.5a
  • Fusible link 3 60a
  • G2 (at right side of firewall)
  • G3 (at right kick panel)
  • Hot at all times
  • Hot in on
  • Hot in on or start
  • Hydraulic unit
  • Joint connector 1 (left side of dash)
  • Junction block (left end of dash)
  • Left front wheel speed sensor (on left front hub/ spindle assembly)
  • Left rear wheel speed sensor (on left rear wheel)
  • Motor
  • Nca
  • Off
  • Right front wheel speed sensor (on right front hub/ spindle assembly)
  • Right rear wheel speed sensor (on right rear wheel)
  • S002
  • S167
  • S168
  • Stop light switch (on brake pedal bracket)
  • Tcl warning
  • W/tcl
