Электросхемы Система Фар Dodge Stratus R/T 2005

Система Фар

Электросхема фар для Dodge Stratus R/T 2005

Электросхема фар для Dodge Stratus R/T 2005 - Список элементов:

• (at front of left front fender) g10
• (at left kick panel)
• (at left kick panel) g13
• (at left kick panel) g14
• (at left side of engine compartment) s004
• (behind left side of dash, near junction box)
• (behind lower center of dash) g15
• (behind right headlight) g1
• (low)
• A-10x
• A-11x
• A-24
• A-34
• A-41
• A-42
• A-42 a-41
• A-43
• A-44
• A-44 a-43
• Beam ind
• C-101
• C101
• C301
• C308
• C312
• C318
• C319
• Column switch
• Column- ecu
• Combination meter
• Connector
• Connector (dlc)
• Data link
• Dimmer/passing switch
• Engine compartment relay box (left side of engine compartment, in front of wheel housing)
• Etacs- ecu
• Fog ind
• Fog light relay
• Foglight switch
• Front- ecu
• Front-ecu (in engine compartment relay box)
• Fuse 10 15a
• Fuse 16 10a
• Fuse 17 10a
• Fuse 18 10a
• Fuse 19 10a
• Fuse 20 7.5a
• Fuse 22 10a
• Fuse 23 7.5a
• Fuse 6 15a
• G1 (behind right headlight)
• G10 (at front of left front fender)
• G13
• Head on
• Head- light relay (high)
• Head- light relay (low)
• Hot at all times
• Hot in on
• Hot in on or start
• Illum
• Interior lights system
• J/c 1 (left side of dash)
• J/c 2 (left side of dash)
• Junction block (left end of dash)
• Left door switch
• Left foglight
• Left headlight
• Lighting switch
• Off
• Park
• Red
• Right foglight
• Right headlight
• S005
• S050
• S052
• S054 (low)
• S059
• S067
• S069
• S097
• S104
• Sebring
• Solid state
• Stratus
