Электросхемы СИСТЕМА КОНДИЦИОНЕРА Dodge Stratus R/T 2005

СИСТЕМА КОНДИЦИОНЕРА

2.4L

2.4L, Электросхема кондиционера с ручный управлением (1 из 2) для Dodge Stratus R/T 2005

2.4L, Электросхема кондиционера с ручный управлением (1 из 2) для Dodge Stratus R/T 2005 - Список элементов:

• (at left kick panel) g13
• (behind center of dash) s060
• (behind center of dash) s079
• (behind center of dash) s085
• (behind lower center of dash) g15
• (behind right side of dash) s074
• A/c sensor (inlet side) (on hvac unit)
• A/c sensor (outlet side) (on hvac unit)
• A/c switch
• Automatic compressor controller (behind right side of dash)
• Blower motor (under right side of dash)
• Blower relay
• Blower switch
• C308
• C311
• Def
• Defroster switch
• Foot
• Fuse 30a
• Fuse 7.5a
• G15 (behind lower center of dash)
• Gnd
• Hot at all times
• Hot in on
• Illum
• Ind
• Inside
• Interior lights system
• Joint connector (left side of dash)
• Junction block (left end of dash)
• Nca
• Off
• Outside
• Outside/inside air selection damper control motor
• Resistor

2.4L, Электросхема кондиционера с ручный управлением (2 из 2) для Dodge Stratus R/T 2005

2.4L, Электросхема кондиционера с ручный управлением (2 из 2) для Dodge Stratus R/T 2005 - Список элементов:

• (at front of left front fender) g10
• (behind center of dash) s110
• (behind left side of dash) s052
• (behind lower right side of dash)
• A/c compressor assembly
• A/c compressor clutch
• A/c compressor clutch relay
• A/t
• A30
• A30-1
• C109
• C110
• C113
• C114
• C117
• C120
• Condenser fan motor (behind radiator)
• Dual pressure switch (on a/c receiver assembly, right front of engine compartment)
• Engine compartment relay box (left side of engine compartment, in front of wheel housing)
• Engine control (m/t)
• Engine controls system
• Engine coolant temperature sensor (on rear of cylinder head)
• Fan control module (behind radiator fan)
• Fan control relay
• Fuse 10a
• Fuse 20a
• Fusible link 2 50a
• High pressure side
• Hot at all times
• Low pressure side
• M/t
• Mfi relay
• Module
• Nca
• Off
• Powertrain control (a/t)
• Radiator fan motor (behind radiator)
• Red
• Refrigerant temperature switch
• S111 (behind center of dash)

3.0L

3.0L, Электросхема кондиционера с ручный управлением (1 из 2) для Dodge Stratus R/T 2005

3.0L, Электросхема кондиционера с ручный управлением (1 из 2) для Dodge Stratus R/T 2005 - Список элементов:

• (at left kick panel) g13
• (behind center of dash) s060
• (behind center of dash) s079
• (behind center of dash) s085
• (behind lower center of dash) g15
• (behind right side of dash) s074
• (on hvac unit)
• A/c sensor (inlet side) (on hvac unit)
• A/c sensor (outlet side)
• A/c switch
• Automatic compressor controller (behind right side of dash)
• Blower motor (under right side of dash)
• Blower relay
• Blower switch
• C14
• C15
• C308
• C311
• Def
• Defroster switch
• Foot
• Fuse 30a
• Fuse 7.5a
• G15 (behind lower center of dash)
• Gnd
• Hot at all times
• Hot in on
• Illum
• Ind
• Inside
• Interior lights system
• Joint connector (left side of dash)
• Junction block (left end of dash)
• Nca
• Off
• Outside
• Outside/inside air selection damper control motor
• Pnk
• Resistor

3.0L, Электросхема кондиционера с ручный управлением (2 из 2) для Dodge Stratus R/T 2005

3.0L, Электросхема кондиционера с ручный управлением (2 из 2) для Dodge Stratus R/T 2005 - Список элементов:

• (at front of left front fender) g10
• (at rear of engine) s048
• (behind left side of dash) s052
• (behind left side of dash) s058
• A/c compressor assembly
• A/c compressor clutch
• A/c compressor clutch relay
• A/t
• A30
• A30-1
• C111
• C112
• C115
• C118
• C119
• C122
• Condenser fan motor (behind radiator)
• Distributor assembly (on rear of right cylinder head)
• Dual pressure switch (on a/c receiver assembly, right front of engine compartment)
• Engine compartment relay box (left side of engine compartment, in front of wheel housing)
• Engine controls system
• Engine coolant temperature sensor (on rear of engine, near thermostat housing)
• Fan control module (behind radiator fan)
• Fan control relay
• Fuse 10a
• Fuse 20a
• Fusible link 2 50a
• G4 (on right side of engine)
• High pressure side
• Hot at all times
• Lock sensor
• Low pressure side
• M/t
• Mfi relay
• Nca
• Off
• Pnk
• Powertrain control module (a/t) engine control module (m/t) (behind lower right side of dash)
• Radiator fan motor (behind radiator)
• Red
• Refrigerant temperature switch
• S033
• S131 (behind red center of dash)
