ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag для Audi A6 Avant Quattro 1998

Электросхема подушек безопасности SRS AirBag для Audi A6 Avant Quattro 1998 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема подушек безопасности SRS AirBag для Audi A6 Avant Quattro 1998 - Список элементов:

  • (below left side of dash) data link connector
  • (lower left "a" pillar) g900
  • Acc
  • Airbag control module (below front of center console)
  • Airbag malfunction indicator lamp
  • Airbag spiral spring
  • Center rear seat belt tensioner igniter (w/ undivided rear seatback)
  • Central locking control module
  • Combination processor
  • Driver seat belt tensioner igniter
  • Driver side airbag crash sensor
  • Driver side airbag igniter
  • Driver's airbag igniter
  • G900 (lower left "a" pillar)
  • Hot at all times
  • Ignition switch
  • Instrument cluster
  • J429
  • Left front "a" pillar micro switch
  • Left rear seat belt tensioner igniter
  • Left rear seat occupancy sensor
  • Left rear side airbag igniter
  • Lock
  • Nca
  • Nca nca
  • Passenger seat belt tensioner igniter
  • Passenger seat occupancy sensor
  • Passenger side airbag crash sensor
  • Passenger side airbag igniter
  • Passenger's airbag igniter
  • Red
  • Right front "a" pillar micro switch
  • Right rear seat belt tensioner igniter
  • Right rear seat occupancy sensor
  • Right rear side airbag igniter
  • Run
  • Start
  • T16
  • T32
