TRANSMISSION

A/T Wiring Diagram for Suzuki Esteem GLX 1999

AT Wiring Diagram for Suzuki Esteem GLX 1999 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file

List of elements for A/T Wiring Diagram for Suzuki Esteem GLX 1999:

  • (right of steering column)
  • A/t vss (on transaxle)
  • C21
  • Cruise control system
  • Data link connector (right of steering column)
  • Diagnosis connector 2
  • E06
  • E07
  • E14
  • E16
  • E18
  • E25
  • E26
  • E92
  • Engine control module (behind glove box)
  • Forward clutch cylinder revolution sensor (right rear of transaxle)
  • Fuse 21 15a
  • Fuse 23 20a
  • Fuse 8 20a
  • G131 (bottom of intake manifold)
  • G200 (left kick panel)
  • Hot at all times
  • Hot in run or start
  • J/c
  • J/c (left side of steering column)
  • Junction fuse block
  • Nca
  • O/d switch
  • Red
  • Relay box (left side of eng compt)
  • Shift interlock system
  • Shift solenoid valves (on transaxle)
  • Starting/ charging system
  • Transmission control module (behind dash, right of steering column)
  • Transmission range switch
