Wiring Diagram VW SURAN 2011 - Battery Starter Generator Alternator Voltage regulator
| A | Battery |
| B | Starter |
| C | Generator Alternator |
| C1 | Voltage regulator |
| J623 | Engine control unit |
| S162 | Fuse 1 30 in battery fuse holder |
| S163 | Fuse 2 30 in battery fuse holder |
| S179 | Fuse 7 30 in battery fuse holder |
| S180 | Fuse 8 30 in battery fuse holder |
| S269 | Fuse 11 30 in battery fuse holder |
| S270 | Fuse 12 30 in battery fuse holder |
| T1j | Fitting connector single on starter |
| T2ak | Fitting connector 2pin on engine compartment |
| T2ar | Fitting connector 2pin on generator alternator |
| 1 | Earth strap battery body |
| 49 | Earth point near the battery |
| 507 | Screw connection 30 battery fuse holder |
| Until February 2011 | |
| From February 2011 |
Wiring Diagram VW SURAN 2011 - Ignition switch Xcontact relief relay
| D | Ignition switch |
| J59 | Light switch |
| J623 | Engine control unit |
| SC2 | Fuse 2 on fuse holder C |
| T6d | Fitting connector 6pin in Xcontact relief relay |
| T8a | Fitting connector 8pin on ignition switch |
| 366 | Earth connection 1 in main harness |
| 606 | Earth point under the centre console near the selection lever |
| B272 | Positive connection 30 on main harness |
| B275 | Positive connection 87 on main harness |
| B298 | Positive connection 2 30 on main harness |
| B300 | Positive connection 4 30 on main harness |
| B729 | Connection 1 50 on main harness |
| Only for vehicles with interactive system |
Wiring Diagram VW SURAN 2011 - Clutch position sensor Automatic transmission control unit Clutch actuator valve Gear selection valve 1 Gear selection valve 2 Gear selection valve 3
| G476 | Clutch position sensor |
| J217 | Automatic transmission control unit |
| N255 | Clutch actuator valve |
| N284 | Gear selection valve 1 |
| N285 | Gear selection valve 2 |
| N286 | Gear selection valve 3 |
| T2dz | Fitting connector 2pin on clutch actuator valve |
| T2ea | Fitting connector 2pin on gear selection valve 1 |
| T2eb | Fitting connector 2pin on gear selection valve 2 |
| T2ec | Fitting connector 2pin on gear selection valve 3 |
| T4aj | Fitting connector 4pin on clutch position sensor |
| T14c | Fitting connector 14 poles under gearshift mechanism cover |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| Until February 2011 | |
| From February 2011 |
Wiring Diagram VW SURAN 2011 - Transmission rotation sensor Gear identification sensor Gear identification sensor 2 Automatic transmission control unit
| G182 | Transmission rotation sensor |
| G604 | Gear identification sensor |
| G616 | Gear identification sensor 2 |
| J217 | Automatic transmission control unit |
| T2dy | Fitting connector 2pin on gearbox input speed sender |
| T4ak | Fitting connector 4pin on gear identification sensor |
| T4al | Fitting connector 4pin on gear identification sensor 2 |
| T14b | Fitting connector 14 poles under gearshift mechanism cover |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| 12 | Earth point in engine compartment left |
Wiring Diagram VW SURAN 2011 - Brake light switch Brake pedal switch Transmission hydraulic pressure sensor Automatic transmission control unit Gearbox hydraulic pump relay Hydraulic transmission pump
| F | Brake light switch |
| F47 | Brake pedal switch |
| G270 | Transmission hydraulic pressure sensor |
| J104 | ABS control unit |
| J217 | Automatic transmission control unit |
| J510 | Gearbox hydraulic pump relay |
| J217 | Automatic transmission control unit |
| J510 | Gearbox hydraulic pump relay |
| J623 | Engine control unit |
| V387 | Hydraulic transmission pump |
| T2dx | Fitting connector 2pin on hydraulic transmission pump |
| T3ap | Fitting connector 3pin on transmission hydraulic pressure sensor |
| T4m | Fitting connector 4pin on brake pedal switch |
| T6ah | Fitting connector 6pin on hydraulic transmission pump relay |
| T14b | Fitting connector 14 poles under gearshift mechanism cover |
| T38a | Fitting connector 38 poles on ABS control unit |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| B277 | Positive connection 1 15a on main harness |
| B335 | Connection 1 54 on main harness |
| D216 | Connection hydraulic pump warning lamp on main harness |
| Until February 2011 | |
| From February 2011 |
Wiring Diagram VW SURAN 2011 - Driver door contact switch Automatic transmission control unit Selector lever sensor control unit
| F2 | Driver door contact switch |
| J104 | ABS control unit |
| J217 | Automatic transmission control unit |
| J234 | Airbag control unit |
| J393 | Central control unit for the convenience system |
| J446 | Control unit for parking aid |
| J587 | The Selector lever sensor control unit |
| J623 | Engine control unit |
| R | Radio |
| T1c | Fitting connector single on Driver door contact switch |
| T1q | Fitting connector single on Driver door contact switch |
| T8f | Fitting connector 8pin on radio |
| T10g | Fitting connector 10 poles on selector lever sensor control unit |
| T16a | Fitting connector 16 poles in diagnosis |
| T16e | Fitting connector 16 poles on control unit for parking aid |
| T23a | Fitting connector 23 poles on central control unit for the convenience system |
| T38a | Fitting connector 38 poles on ABS control unit |
| T75a | Fitting connector 75 poles on airbag control unit |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| B383 | Connection 1 CANbus 'high' command on main harness |
| B390 | Connection 1 CANbus 'low' command on main harness |
| B625 | Connection diagnostic cable K on main harness |
Wiring Diagram VW SURAN 2011 - Automatic transmission control unit
| J217 | Automatic transmission control unit |
| J623 | Engine control unit |
| T14c | Fitting connector 14 poles under gearshift mechanism cover |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| 12 | Earth point in engine compartment left |
| 379 | Earth connection 14 in main harness |
Wiring Diagram VW SURAN 2011 - Park brake control switch Brake oil level warning contact Automatic transmission control unit
| F9 | Handbrake warning switch |
| F34 | Brake oil level warning contact |
| J217 | Automatic transmission control unit |
| T2v | Fitting connector 2pin on Park brake control switch |
| T2ai | Fitting connector 2pin on Brake oil level warning contact |
| T16a | Fitting connector 16 poles in diagnosis |
| T80b | Fitting connector 80 poles on automatic transmission control unit |
| 367 | Earth connection 2 in main harness |
| 377 | Earth connection 12 in main harness |
| 380 | Earth connection 15 in main harness |
| 605 | Earth point in upper steering column area |
| 606 | Earth point under the centre console near the selection lever |
| Only for vehicles with buttons on steering wheel for radio command |
Wiring Diagram VW SURAN 2011 - Starter motor relay X contact relief relay 2 Starter motor relay 2
| J53 | Starter motor relay |
| J339 | X contact relief relay 2 |
| J623 | Engine control unit |
| J695 | Starter motor relay 2 |
| T9o | Fitting connector 9pin on starter relay |
| T9p | Fitting connector 9pin on starter relay 2 |
| T9q | Fitting connector 9pin in Xcontact relief relay 2 |
| T14a | Fitting connector 14 poles on left engine compartment |
| 368 | Earth connection 3 in main harness |
| 606 | Earth point under the centre console near the selection lever |
| B467 | Connection 3 on main harness |
Wiring Diagram VW SURAN 2011 - Control unit on the steering wheel 'Tiptronic' downshift switch on the steering wheel Multifunction controls on the left side of the steering wheel Airbag coil connector and return ring with slip ring Horn actuator
| E221 | Control unit on the steering wheel |
| E439 | 'Tiptronic' downshift switch on the steering wheel |
| E440 | Multifunction controls on the left side of the steering wheel |
| F138 | Airbag coil connector and return ring with slip ring |
| H | Horn activator |
| J4 | Dual tone horn relay |
| T3an | Fitting connector 3pin on multifunction controls on the left side of the steering wheel |
| T5g | Fitting connector 5pin on airbag coil connector and return ring with slip ring |
| T5k | Fitting connector 5pin on airbag coil connector and return ring with slip ring |
| T6ai | Fitting connector 6pin in steering wheel |
| T9h | Fitting connector 9pin in dual tone horn relay |
| 109 | Earth connection in the airbag wiring harness |
| Only for vehicles with interactive system | |
| Only for vehicles with buttons on steering wheel for radio command |
Wiring Diagram VW SURAN 2011 - Control unit on the steering wheel 'Tiptronic' up shift switch on the steering wheel Multifunction controls on the left side of the steering wheel Multifunction controls on the right side of the steering wheel
| E221 | Control unit on the steering wheel |
| E438 | 'Tiptronic' up shift switch on the steering wheel |
| E440 | Multifunction controls on the left side of the steering wheel |
| E441 | Multifunction controls on the right side of the steering wheel |
| T3ao | Fitting connector 3pin on multifunction controls on the right side of the steering wheel |
| T8l | Fitting connector 8pin on multifunction controls on the left side of the steering wheel |
| T8m | Fitting connector 8pin on multifunction controls on the right side of the steering wheel |
Wiring Diagram VW SURAN 2011 - Fuses
| SC9 | Fuse 9 on fuse holder C |
| SC13 | Fuse 13 on fuse holder C |
| SC19 | Fuse 19 on fuse holder C |
| SC21 | Fuse 21 on fuse holder C |
| SB38 | Fuse 38 on fuse holder B |
| SB40 | Fuse 40 on fuse holder B |
| SB48 | Fuse 48 on fuse holder B |
| T3c | Fitting connector 3pin on 12volt socket |
| U5 | 12volt socket |
| B273 | Positive connection 15 on main harness |
| B299 | Positive connection 3 30 on main harness |
| Only for vehicles with interactive system | |
| Only for vehicles with buttons on steering wheel for radio command |
Wiring Diagram VW SURAN 2011 - Tachometer Speedometer Control unit w indicator on the combined instrument Combined instrument Alternator control light
| G5 | Tachometer |
| G21 | Speedometer |
| J285 | Control unit w indicator on the combined instrument |
| J393 | Central control unit for the convenience system |
| K | Combined instrument |
| K2 | Alternator control light |
| R | Radio |
| T8f | Fitting connector 8pin on radio |
| T23a | Fitting connector 23 poles on central control unit for the convenience system |
| T32a | 32pin connector |
| 375 | Earth connection 10 in main harness |
| B340l | Connection 1 58d on main harness |
| B518 | Connection 86s on main harness |
| Only for vehicles with buttons on steering wheel for radio command |
