VW SURAN 2011 – Fog headlight from March 2010 . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW SURAN
  4. >VW SURAN 2011
  5. >VW SURAN 2011 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW SURAN 2011 - Battery Starter Generator Alternator Voltage regulator



Wiring Diagram VW SURAN 2011 - Battery Starter Generator Alternator Voltage regulator https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
BStarter
CGenerator Alternator
C1Voltage regulator
J623Engine control unit
S162Fuse 1 30 in battery fuse holder
S163Fuse 2 30 in battery fuse holder
T1jFitting connector single on starter
T2akFitting connector 2pin on engine compartment
T2arFitting connector 2pin on generator alternator
  1 Earth strap battery body
  49 Earth point near the battery
  507 Screw connection 30 battery fuse holder

Wiring Diagram VW SURAN 2011 - Ignition switch Xcontact relief relay



Wiring Diagram VW SURAN 2011 - Ignition switch Xcontact relief relay https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition switch
J12Headlight main beam relay
J59Xcontact relief relay
J331Dipped beam relay
SC2Fuse 2 on fuse holder C
SC17Fuse 17 on fuse holder C
T6dFitting connector 6pin in Xcontact relief relay
T8aFitting connector 8pin on ignition switch
T9aFitting connector 6pin in dipped beam relay
T9bFitting connector 6pin in headlight main beam relay
  B272 Positive connection 30 on main harness
  B275 Positive connection 87 on main harness
  B298 Positive connection 2 30 on main harness
  B346 Connection 1 75 on main harness

Wiring Diagram VW SURAN 2011 - Light switch Flashingturn light switch Headlight dipper and flasher switch Parking light switch Horn activator Horn activation contact ring



Wiring Diagram VW SURAN 2011 - Light switch Flashingturn light switch Headlight dipper and flasher switch Parking light switch Horn activator Horn activation contact ring https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E1Light switch
E2Flashingturn light switch
E4Headlight dipper and flasher switch
E19Parking light switch
HHorn activator
H1Horn or dual tone horn
H23 Horn activation contact ring
J2Hazard warning light relay
J331Dipped beam relay
T1gFitting connector single on horn activator
T1hFitting connector single on horn activator
T2zFitting connector 2pin in horn or dual tone horn
T9aFitting connector 9pin in dipped beam relay
T9lFitting connector 9pin on warning light relay
T12aFitting connector 12 poles in light switch
  678 Earth point on steering wheel
  B300 Positive connection 4 30 on main harness
  B662 Connection 2 56b on main harness
  B727 Connection 71a on main harness
  B728 Connection 49a on main harness
Only for vehicles with multifunction steering wheel

Wiring Diagram VW SURAN 2011 - Front and rear fog light switch Front and rear fog light switch illumination bulb Fog light relay



Wiring Diagram VW SURAN 2011 - Front and rear fog light switch Front and rear fog light switch illumination bulb Fog light relay https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E23Front and rear fog light switch
L40Front and rear fog light switch illumination bulb
J5Fog light relay
J12Headlight main beam relay
SC7Fuse 7 on fuse holder C
T6iFitting connector 6pin in front and rear fog light switch
T9bFitting connector 9pin in headlight main beam relay
T9rFitting connector 9pin in fog light relay
T16aFitting connector 16 poles in diagnosis
  366 Earth connection 1 in main harness
  367 Earth connection 2 in main harness
  605 Earth point in upper steering column area
  606 Earth point under the centre console near the selection lever
  B644 Connection 3 56a on main harness
Only for CROSS vehicles

Wiring Diagram VW SURAN 2011 - Fuses



Wiring Diagram VW SURAN 2011 - Fuses https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
SB32Fuse 32 on fuse holder B
SB38Fuse 38 on fuse holder B
SC1Fuse 1 on fuse holder C
SC3Fuse 3 on fuse holder C
B273Positive connection 15 on main harness
B338Connection 1 56 on main harness
B642Positive connection 58 on main harness
B726Positive connection 2 58 on main harness
Only for CROSS vehicles

Wiring Diagram VW SURAN 2011 - Rear fog light bulb Left fog light lamp Right fog light lamp Left main beam headlight and fog light bulb Right main beam headlight and fog light bulb



Wiring Diagram VW SURAN 2011 - Rear fog light bulb Left fog light lamp Right fog light lamp Left main beam headlight and fog light bulb Right main beam headlight and fog light bulb https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
L20Rear fog light bulb
L22Left fog light lamp
L23Right fog light lamp
M94Left main beam headlight and fog light bulb
M95Right main beam headlight and fog light bulb
T2aqFitting connector 2pin in left fog light lamp
T2eeFitting connector 2pin in Rear fog light lamp
T2yFitting connector 2pin in right fog light lamp
T4amFitting connector 2pin in left front indicator light lamp
T4anFitting connector 4pin on right main beam headlight and fog light bulb
  21 Earth point near fuel pump
  50 Earth point on left luggage compartment
  372 Earth connection 7 in main harness
  381 Earth connection 16 in main harness
  671 Earth point 1 on left front longitudinal member
  B554 Connection fog light on main harness
Only for CROSS vehicles

Wiring Diagram VW SURAN 2011 - Tachometer Speedometer Control unit w indicator on the combined instrument Combined instrument Alternator control light Left turn signal control light Right turn signal control light



Wiring Diagram VW SURAN 2011 - Tachometer Speedometer Control unit w indicator on the combined instrument Combined instrument Alternator control light Left turn signal control light Right turn signal control light https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G5Tachometer
G21Speedometer
J285Control unit w indicator on the combined instrument
KCombined instrument
K2Alternator control light
K65Left turn signal control light
K94Right turn signal control light
M5Left front indicator light lamp
M7Right front indicator light lamp
RRadio
T2xFitting connector 2pin in right front indicator light lamp
T2amFitting connector 2pin in left front indicator light lamp
T8fFitting connector 8pin on radio
T32aFitting connector 32 poles on Control unit w indicator on the combined instrument
  B340 Connection 1 58d on main harness
  B518 Connection 86s on main harness
  B630 Connection turn signal left on main harness
  B631 Connection turn signal right on main harness
