| A | Battery |
| B | Starter |
| C | Generator Alternator |
| C1 | Voltage regulator |
| J623 | Engine control unit |
| S162 | Fuse 1 30 in battery fuse holder |
| S163 | Fuse 2 30 in battery fuse holder |
| S164 | Fuse 3 30 in battery fuse holder |
| S180 | Fuse 8 30 in battery fuse holder |
| T1j | Fitting connector single on starter |
| T2ak | Fitting connector 2pin on engine compartment |
| T2ar | Fitting connector 2pin on generator alternator |
| 1 | Earth strap battery body |
| 49 | Earth point near the battery |
| 507 | Screw connection 30 battery fuse holder |
| Until February 2011 |
| From February 2011 |
| D | Ignition switch |
| J59 | Xcontact relief relay |
| SC2 | Fuse 2 on fuse holder C |
| T6d | Fitting connector 6pin in Xcontact relief relay |
| T8a | Fitting connector 8pin on ignition switch |
| 366 | Earth connection 1 in main harness |
| 606 | Earth point under the centre console near the selection lever |
| B272 | Positive connection 30 on main harness |
| B298 | Positive connection 2 30 on main harness |
| B300 | Positive connection 4 30 on main harness |
| B346 | Connection 1 75 on main harness |
| Only for vehicles with convenience system |
| E9 | Fresh air blower switch |
| N24 | Fresh air blower series resistor with overheating fuse |
| SB28 | Fuse 28 on fuse holder B |
| SB38 | Fuse 38 on fuse holder B |
| T2ba | Fuse 16 on fuse holder C |
| T5l | Fitting connector 5pin on fresh air blower series resistor with overheating fuse |
| T5m | Fitting connector 5pin on fresh air blower switch |
| T8d | Fitting connector 8pin on behind dash panel centre |
| V2 | Fresh air fan |
| 97 | Earth connection 1 on air conditioning wiring harness |
| 606 | Earth point under the centre console near the selection lever |
| B273 | Positive connection 15 on main harness |
| B299 | Positive connection 3 30 on main harness |
| L6 | Connection 2 on wiring harness for box of the air conditioning |
| L8 | Connection 4 on wiring harness for box of the air conditioning |
| J101 | Radiator fan 2nd speed relay |
| J209 | Fresh air blower and radiator fan relay |
| J623 | Engine control unit |
| N39 | Radiator fan series resistor |
| T2df | Fitting connector 2pin on radiator fan |
| T3ae | Fitting connector 3pin on Radiator fan series resistor |
| T9c | Fitting connector 9pin fresh air blower and radiator fan relay |
| T9d | Fitting connector 9pin on Radiator fan 2nd speed relay |
| V7 | Radiator fan |
| 378 | Earth connection 13 in main harness |
| 671 | Earth point 1 on left front longitudinal member |
| B320 | Positive connection 6 30a on main harness |
| B322 | Positive connection 8 30a on main harness |
| Until February 2011 |
| From February 2011 |
| G65 | High pressure sensor |
| J365 | Air conditioning system switchoff relay |
| J393 | Central control unit for the convenience system |
| J623 | Engine control unit |
| N25 | Air conditioning system magnetic clutch |
| SB38 | Fuse 42 on fuse holder B |
| SC15 | Fuse 15 on fuse holder C |
| SC16 | Fitting connector 2pin on air conditioning system magnetic clutch |
| T2dc | Fitting connector 2pin on air conditioning system magnetic clutch |
| T3j | Fitting connector 3pin on high pressure sensor |
| T9g | Fitting connector 9pin on Air conditioning system switchoff relay |
| T23a | Fitting connector 23 poles on central control unit for the convenience system |
| B275 | Positive connection 87 on main harness |
| B277 | Positive connection 1 15a on main harness |
| B301 | Positive connection 5 30 on main harness |
| Only for vehicles with convenience system |
| G5 | Tachometer |
| G21 | Speedometer |
| J285 | Control unit w indicator on the combined instrument |
| J393 | Central control unit for the convenience system |
| J623 | Engine control unit |
| K | Combined instrument |
| K2 | Alternator control light |
| R | Radio |
| T8f | Fitting connector 8pin on radio |
| T16a | Fitting connector 16 poles in diagnosis |
| T23a | Fitting connector 23 poles on central control unit for the convenience system |
| T32a | Fitting connector 32 poles on Control unit w indicator on the combined instrument |
| 367 | Earth connection 2 in main harness |
| 605 | Earth point in upper steering column area |
| 606 | Earth point under the centre console near the selection lever |
| B321 | Positive connection 7 30a on main harness |
| B518 | Connection 86s on main harness |
| B625 | Connection diagnostic cable K on main harness |
