VW SURAN 2011 – Parking aid sensor PDC from March 2010 . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW SURAN
  4. >VW SURAN 2011
  5. >VW SURAN 2011 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW SURAN 2011 - Battery Starter Generator Alternator Voltage regulator



Wiring Diagram VW SURAN 2011 - Battery Starter Generator Alternator Voltage regulator https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
BStarter
CGenerator Alternator
C1Voltage regulator
J623Engine control unit
S162Fuse 1 30 in battery fuse holder
S163Fuse 2 30 in battery fuse holder
T1jFitting connector single on starter
T2akFitting connector 2pin on engine compartment
T2arFitting connector 2pin on generator alternator
  1 Earth strap battery body
  49 Earth point near the battery
  507 Screw connection 30 battery fuse holder

Wiring Diagram VW SURAN 2011 - Ignition switch Xcontact relief relay



Wiring Diagram VW SURAN 2011 - Ignition switch Xcontact relief relay https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition switch
J59Xcontact relief relay
SB48Fuse 48 on fuse holder B
SC2Fuse 2 on fuse holder C
T3cFitting connector 3pin on 12volt socket
T6dFitting connector 6pin in Xcontact relief relay
T8aFitting connector 8pin on ignition switch
U512volt socket
  B272 Positive connection 30 on main harness
  B275 Positive connection 87 on main harness
  B298 Positive connection 2 30 on main harness
  B300 Positive connection 4 30 on main harness
  B346 Connection 1 75 on main harness

Wiring Diagram VW SURAN 2011 - Parking aid sensor left rear Parking aid sensor left rear center Parking aid sensor right rear center Parking aid sensor right rear Warning buzzer for rear parking aid Control unit for parking aid



Wiring Diagram VW SURAN 2011 - Parking aid sensor left rear Parking aid sensor left rear center Parking aid sensor right rear center Parking aid sensor right rear Warning buzzer for rear parking aid Control unit for parking aid https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G203Parking aid sensor left rear
G204Parking aid sensor left rear center
G205Parking aid sensor right rear center
G206Parking aid sensor right rear
H15Warning buzzer for rear parking aid
J446Control unit for parking aid
T2edFitting connector 2pin on warning buzzer for rear parking aid
T3aqFitting connector 3pin on parking aid sensor left rear
T3arFitting connector 3pin on parking aid sensor left rear center
T3asFitting connector 3pin on parking aid sensor right rear center
T3atFitting connector 3pin on parking aid sensor right rear
T6ajFitting connector 6pin behind bumper left rear
T12fFitting connector 12 poles on control unit for parking aid
T16eFitting connector 16 poles on control unit for parking aid
  352 Earth connection parking aid in rear bumper wiring harness
  X68 Connection parking aid in rear bumper wiring harness

Wiring Diagram VW SURAN 2011 - Reversing light switch Control unit for parking aid



Wiring Diagram VW SURAN 2011 - Reversing light switch Control unit for parking aid https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F4Reversing light switch
J104ABS control unit
J234Airbag control unit
J393Central control unit for the convenience system
J446Control unit for parking aid
J623Engine control unit
J879Control unit for interactive system
M16Left reversing light lamp
RRadio
T2alFitting connector 2pin on reversing light switch
T5pFitting connector 5pin for Right tail light
T5qFitting connector 5pin for left tail light
T8fFitting connector 8pin on radio
T10dFitting connector 10 poles on control unit for interactive system
T16aFitting connector 16 poles in diagnosis
T16eFitting connector 16 poles on control unit for parking aid
T23aFitting connector 23 poles on central control unit for the convenience system
T38aFitting connector 38 poles on ABS control unit
T75aFitting connector 75 poles on airbag control unit
  366 Earth connection 1 in main harness
  606 Earth point under the centre console near the selection lever
  B336 Connection 2 54 on main harness
  B625 Connection diagnostic cable K on main harness
From July 2010

Wiring Diagram VW SURAN 2011 - Tachometer Speedometer Control unit w indicator on the combined instrument Combined instrument Alternator control light



Wiring Diagram VW SURAN 2011 - Tachometer Speedometer Control unit w indicator on the combined instrument Combined instrument Alternator control light https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G5Tachometer
G21Speedometer
J285Control unit w indicator on the combined instrument
J393Central control unit for the convenience system
KCombined instrument
K2Alternator control light
RRadio
SB37Fuse 37 on fuse holder B
SB38Fuse 38 on fuse holder B
T8fFitting connector 8pin on radio
T16aFitting connector 16 poles in diagnosis
T23aFitting connector 23 poles on central control unit for the convenience system
T32aFitting connector 32 poles on Control unit w indicator on the combined instrument
  367 Earth connection 2 in main harness
  605 Earth point in upper steering column area
  606 Earth point under the centre console near the selection lever
  B273 Positive connection 15 on main harness
  B277 Positive connection 1 15a on main harness
  B518 Connection 86s on main harness
