VW NEW BEETLE 2002 – Telephone . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2002
  5. >VW NEW BEETLE 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2002 - Telephone microphone - mobile telephone - earth connection



Wiring Diagram VW NEW BEETLE 2002 - Telephone microphone - mobile telephone - earth connection https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J412Mobile phone operating electronics control unit
RRadio
R38Telephone microphone
R54Mobile telephone
T8a8-pin connector, on radio
T8t8-pin connector, in headlining wiring harness
T1313-pin connector
T1818-pin connector, on operating electronics control unit, mobile telephone
T2020-pin connector, yellow/green/blue, on radio
   45 Earth point, behind dash panel - centre
   255 Earth connection -1-, in radio wiring harness
   277 Earth connection -3-, in interior wiring harness

Wiring Diagram VW NEW BEETLE 2002 - Aerial for radio - telephone - fuses



Wiring Diagram VW NEW BEETLE 2002 - Aerial for radio - telephone - fuses https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
E20Switches and instruments, lighting control
J412Mobile phone operating electronics control unit
RRadio
R51Radio/telephone aerial
S8Fuse in fuse box/relay plate
S12Fuse in fuse box/relay plate
T1Single connector
T1a1-pin connector
T6c6-pin connector, on lighting control/adjuster headlight range
T1818-pin connector, on operating electronics control unit, mobile telephone
   500 Screw connection -1- (30), on relay plate
   A2 Positive (+) connection (15), in dash panel wiring harness
   A4 Positive (+) connection (58b), in dash panel wiring harness
   B231 Positive (+) connection -5- (30a), in interior wiring harness
