VW NEW BEETLE 2002 – Heated front seats . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2002
  5. >VW NEW BEETLE 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2002 - Heated driver's seat control unit - temperature sensor - heated driver's seat - heated driver's seat backrest



Wiring Diagram VW NEW BEETLE 2002 - Heated driver https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition/starter switch
E20Switches and instruments - lighting control
E94Heated driver's seat adjuster
G59Driver's seat temperature sensor
J131Heated driver's seat control unit
L44Seat heating switch light bulb
S5Fuse in fuse box/relay plate
T2g2-pin connector, under driver's seat
T6c6-pin connector, on lighting control/adjuster headlight range
T6r6-pin connector, on heated driver's seat control unit
T6t6-pin connector, green, under driver's seat
Z6Heated driver's seat
Z7Heated driver's seat backrest
Z31Seat lateral support heater, driver's seat
   96 Earth connection -1-, in seat heating wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A4 Positive (+) connection (58b), in dash panel wiring harness
   A20 Positive (+) connection (15a), in dash panel wiring harness

Wiring Diagram VW NEW BEETLE 2002 - Heated front passenger's seat control unit - temperature sensor - heated front passenger's seat - heated front passenger's seat backrest



Wiring Diagram VW NEW BEETLE 2002 - Heated front passenger https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E95Heated front passenger's seat adjuster
G60Front passenger's seat temperature sensor
J132Heated front passenger's seat control unit
L44Seat heating switch light bulb
S244Fuse in fuse box
T2h2-pin connector, under front passenger's seat
T6s6-pin connector, on heated front passenger seat control unit
T6u6-pin connector, green, under front passenger's seat
Z8Heated front passenger's seat
Z9Heated front passenger's seat backrest
   81 Earth connection -1-, in dash panel wiring harness
   96 Earth connection -1-, in seat heating wiring harness
   501 Screw connection -2- (30), on relay plate
   A32 Positive (+) connection (30), in dash panel wiring harness
   A40 Positive (+) connection -1- (30), in dash panel wiring harness
