VW NEW BEETLE 2002 – Headlights without headlight range control . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2002
  5. >VW NEW BEETLE 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2002 - Lighting switch - fog light relay



Wiring Diagram VW NEW BEETLE 2002 - Lighting switch - fog light relay https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
E1Lighting switch
E23Front and rear fog light switch
J5Fog light relay
T1717-pin connector, connector on lighting switch
   A3 Positive (+) connection (58), in dash panel wiring harness
   A37 Connection (58a), in dash panel wiring harness
   A43 Connection (57L), in dash panel wiring harness
   A44 Connection (57R), in dash panel wiring harness
   B167 Connection (56b), in interior wiring harness
*Left-hand drive models only
**Right-hand drive models only

Wiring Diagram VW NEW BEETLE 2002 - Fuses - hazard warning light switch - steering column switch - headlight dipper/flasher switch



Wiring Diagram VW NEW BEETLE 2002 - Fuses - hazard warning light switch - steering column switch - headlight dipper/flasher switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
E2Turn signal switch
E3Hazard warning light switch
E4Headlight dipper/flasher switch
E19Parking light switch
JHeadlight dipper/flasher relay
S3Fuse in fuse box/relay plate
S4Fuse in fuse box/relay plate
S236Fuse in fuse box
T7a7-pin connector, on hazard warning light switch
T1212-pin connector, steering column switch
   501 Screw connection -2- (30), on relay plate
   A3 Positive (+) connection (58), in dash panel wiring harness
   A5 Positive (+) connection (right turn signal), in dash panel wiring harness
   A6 Positive (+) connection (left turn signal), in dash panel wiring harness
   A32 Positive (+) connection (30), in dash panel wiring harness
   A37 Connection (58a), in dash panel wiring harness
   A80 Connection -1- (X), in dash panel wiring harness
   B141 Positive (+) connection -1- (56a), in interior wiring harness
*Left-hand drive models only
**Right-hand drive models only

Wiring Diagram VW NEW BEETLE 2002 - Fuses - front lighting - front turn signals



Wiring Diagram VW NEW BEETLE 2002 - Fuses - front lighting - front turn signals https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
L1Twin filament bulb/sealed beam insert, left
L22Fog light bulb, left
M1Side light bulb, left
M5Turn signal bulb, front left
M18Side turn signal bulb, left
S19Fuse in fuse box/relay plate
S21Fuse in fuse box/relay plate
S223Fuse in fuse box
T3h3-pin connector, on turn signal front left
T8r8-pin connector, on headlight, left
   131 Earth connection -2-, in engine compartment wiring harness
   A5 Positive (+) connection (right turn signal), in dash panel wiring harness
   A6 Positive (+) connection (left turn signal), in dash panel wiring harness
   A84 Connection (58L), in dash panel wiring harness
   B167 Connection (56b), in interior wiring harness
   C21 Connection (83a), in front fog light wiring harness

Wiring Diagram VW NEW BEETLE 2002 - Fuses - front lighting - front turn signals



Wiring Diagram VW NEW BEETLE 2002 - Fuses - front lighting - front turn signals https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J285Control unit with display in dash panel insert
L2Twin filament bulb/sealed beam insert, right
L23Fog light bulb, right
M3Side light bulb, right
M7Turn signal bulb, front right
M19Side turn signal bulb, right
S18Fuse in fuse box/relay plate
S20Fuse in fuse box/relay plate
S22Fuse in fuse box/relay plate
T3i3-pin connector, on turn signal front right
T8l8-pin connector, on headlight, right
T3232-pin connector, blue, on dash panel insert
   12 Earth point, in engine compartment, left
   85 Earth connection -1-, in engine compartment wiring harness
   A5 Positive (+) connection (right turn signal), in dash panel wiring harness
   A85 Connection (58R), in dash panel wiring harness
   B142 Positive (+) connection -2- (56a), in interior wiring harness
   B167 Connection (56b), in interior wiring harness
   C21 Connection (83a), in front fog light wiring harness
