Wiring Diagram VW NEW BEETLE 2002 - Parking aid control unit - reversing light switch



Wiring Diagram VW NEW BEETLE 2002 - Parking aid control unit - reversing light switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition/starter switch
F4Reversing light switch
J226Starter inhibitor and reversing light relay
J446Parking aid control unit
M17Reversing light bulb, right
S5Fuse in fuse box/relay plate
S7Fuse in fuse box/relay plate
T1010-pin connector, orange, connector point, electronics box, in plenum chamber, left
T12a12-pin connector, black, in moulded wiring harness
T16a16-pin connector, on parking aid control unit
   50 Earth point, on left luggage compartment
   238 Earth connection -1-, in interior wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A20 Connection (15a), in dash panel wiring harness
   A38 Positive (+) connection -2- (15a), in dash panel wiring harness
   B182 Connection (reversing light), in interior wiring harness
*Only models with manual gearbox
**Only models with automatic gearbox

Wiring Diagram VW NEW BEETLE 2002 - Parking aid control unit - rear parking aid sender



Wiring Diagram VW NEW BEETLE 2002 - Parking aid control unit - rear parking aid sender https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G203Rear left parking aid sender
G204Centre rear left parking aid sender
G205Centre rear right parking aid sender
G206Rear right parking aid sender
H15Parking aid warning buzzer
J446Parking aid control unit
T12d12-pin connector, on parking aid control unit
T1616-pin connector, diagnostic connector
T16a16-pin connector, on parking aid control unit
   42 Earth point, next to steering column
   81 Earth connection -1-, in dash panel wiring harness
   135 Earth connection -2-, in dash panel wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
