VW NEW BEETLE 2002 – Rear spoiler, variable . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2002
  5. >VW NEW BEETLE 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2002 - Adjustable rear spoiler control unit - rear spoiler switch



Wiring Diagram VW NEW BEETLE 2002 - Adjustable rear spoiler control unit - rear spoiler switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
E127Adjustable rear spoiler switch
J223Adjustable rear spoiler control unit
J245Sliding sunroof adjustment control unit
T5j5-pin connector, black, in tailgate/bootlid
T5k5-pin connector, black, connector point, right C pillar
T5l5-pin connector, brown, connector point, right C pillar
T5m5-pin connector, brown, in tailgate/bootlid
T5o5-pin connector, on adjustable rear spoiler switch
T6a6-pin connector, on sliding / tilting sunroof
T8t8-pin connector, in headlining wiring harness
T12b2-pin connector, at adjustable rear spoiler control unit
   42 Earth point, next to steering column
   50 Earth point, on left luggage compartment
   81 Earth connection -1-, in dash panel wiring harness
   98 Earth connection, in tailgate/bootlid wiring harness
   135 Earth connection -2-, in dash panel wiring harness
   B130 Connection (sliding sunroof), in interior wiring harness
*Only models with versions with sunroof
**Only models without sliding sunroof

Wiring Diagram VW NEW BEETLE 2002 - Adjustable rear spoiler control unit - fuse



Wiring Diagram VW NEW BEETLE 2002 - Adjustable rear spoiler control unit - fuse https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J104ABS with EDL control unit
J223Adjustable rear spoiler control unit
J245Sliding sunroof adjustment control unit
J393Convenience system central control unit
SB1Fuse -1- on fuse box
T5k5-pin connector, black, connector point, right C pillar
T5m5-pin connector, brown, in tailgate/bootlid
T6a6-pin connector, on sliding / tilting sunroof
T8t8-pin connector, in headlining wiring harness
T12b2-pin connector, at adjustable rear spoiler control unit
T2323-pin connector, connector A, central control unit
   501 Screw connection -2- (30), on relay plate
   A32 Positive (+) connection (30), in dash panel wiring harness
   A40 Positive (+) connection -1- (30), in dash panel wiring harness
   J3 Connection -1-, in ABS wiring harness
   Y3 Positive (+) connection (15), in interior light wiring harness/ sliding sunroof
*Only models with versions with sunroof
**Only models without sliding sunroof

Wiring Diagram VW NEW BEETLE 2002 - Control unit with display for radio and navigation - adjustable rear spoiler control unit - self-diagnosis connection



Wiring Diagram VW NEW BEETLE 2002 - Control unit with display for radio and navigation - adjustable rear spoiler control unit - self-diagnosis connection https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J223Adjustable rear spoiler control unit
J285Control unit with display in dash panel insert
T5j5-pin connector, black, in tailgate/bootlid
T5k5-pin connector, black, connector point, right C pillar
T5l5-pin connector, brown, connector point, right C pillar
T5m5-pin connector, brown, in tailgate/bootlid
T12b2-pin connector, at adjustable rear spoiler control unit
T1616-pin connector, diagnostic connector
T3232-pin connector, blue, on dash panel insert
T32a32-pin connector, green, on dash panel insert
V52Adjustable rear spoiler motor
   A27 Connection (speed signal), in dash panel wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
