VW NEW BEETLE 2002 – Anti-lock brake system (ABS) MK60, ABS, ABS with traction control system (ASR) with electronic differential lock (EDL), ABS with electronic stability program (ESP) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2002
  5. >VW NEW BEETLE 2002 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2002 - Fuses - TCS/ESP button



Wiring Diagram VW NEW BEETLE 2002 - Fuses - TCS/ESP button https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
DIgnition/starter switch
E256TCS/ESP button
J104ABS with EDL/TCS/ESP control unit, in engine compartment, left
L71Traction control switch illumination
S9Fuse in fuse box
S178Fuse -6- (30), in fuse box/battery
S179Fuse -7- (30), in fuse box/battery
T33-pin connector, on fuse box/battery
T6j6-pin connector, on TCS/ESP button
T4747-pin connector, on ABS with EDL/TCS/ESP control unit
  10 Earth point, in plenum chamber
  A2 Positive (+) connection (15), in dash panel wiring harness
  A4 Positive (+) connection (58b), in dash panel wiring harness
  A132 Connection (TCS/ESP), in dash panel wiring harness
  B149 Positive (+) connection -2- (15a), in interior wiring harness
*Only models with ESP
**Only models with ASR

Wiring Diagram VW NEW BEETLE 2002 - Steering angle sender - ABS valves



Wiring Diagram VW NEW BEETLE 2002 - Steering angle sender - ABS valves https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
FBrake light switch
G85Steering angle sender, on steering column
J104ABS with EDL control unit
J217Automatic gearbox control unit
J223Adjustable rear spoiler control unit
M...Brake light bulb
N133ABS inlet valve, rear right
N134ABS inlet valve, rear left
N135ABS outlet valve, rear right
N136ABS outlet valve, rear left
S15Fuse in fuse box/relay plate
T6k6-pin connector, on steering angle sender
T10a10-pin connector, grey, connector point, electronics box, in plenum chamber, left
T4747-pin connector
  500 Screw connection -1- (30), on relay plate
  A18 Connection (54), in dash panel wiring harness
  A121 Connection (high bus), in dash panel wiring harness
  A122 Connection (low bus), in dash panel wiring harness
  A167 Positive (+) connection -3- (30a), in dash panel wiring harness
  J3 Connection -1-, in ABS wiring harness
*Only models with ESP
**Only models with automatic gearbox
***Only models with air conditioning system only

Wiring Diagram VW NEW BEETLE 2002 - Speed sensor - ABS valves



Wiring Diagram VW NEW BEETLE 2002 - Speed sensor - ABS valves https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G44Rear right speed sensor
G45Front right speed sensor
G46Rear left speed sensor
G47Front left speed sensor
G201Brake pressure sender -1-, on brake master cylinder
J104ABS with EDL/TCS/ESP control unit, in engine compartment, left
N99ABS inlet valve, front right
N100ABS outlet valve, front right
N101ABS inlet valve, front left
N102ABS outlet valve, front left
N125Differential lock valve 1
N126Differential lock valve 2
T2c2-pin connector, near rear right speed sensor
T2d2-pin connector, near rear left speed sensor
T4747-pin connector, on ABS with EDL/TCS/ESP control unit
  D146 Connection (rear left speed sensor +), in engine compartment wiring harness
  D147 Connection (rear left speed sensor -), in engine compartment wiring harness
  D148 Connection (rear right speed sensor +), in engine compartment wiring harness
  D149 Connection (rear right speed sensor -), in engine compartment wiring harness
*Only models with ESP
**Only models with EDL

Wiring Diagram VW NEW BEETLE 2002 - Lateral acceleration sender - yaw rate sender - brake pressure sender -1- - ABS valves



Wiring Diagram VW NEW BEETLE 2002 - Lateral acceleration sender - yaw rate sender - brake pressure sender -1- - ABS valves https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G200Lateral acceleration sender, next to steering column
G202Yaw rate sender, next to steering column
G419ESP sensor unit
J104ABS with EDL/TCS/ESP control unit, in engine compartment, left
N225Electronic stability program switch valve -1-
N226Electronic stability program switch valve -2-
N227Electronic stability program high pressure valve -1-
N228Electronic stability program high pressure valve -2-
T1616-pin connector, diagnostic connector
T4747-pin connector, on ABS with EDL/TCS/ESP control unit
V64ABS hydraulic pump
  A76 Connection (diagnosis wire K), in dash panel wiring harness
  J5 Connection -2-, in ABS wiring harness
  J7 Connection -3-, in ABS wiring harness
*Only models with ESP, from model year 2003 (phased-in modification)
**Only models with ESP up to model year 2002
***Only models with ESP
****Only models without ESP

Wiring Diagram VW NEW BEETLE 2002 - Control unit with display in dash panel insert - handbrake warning switch - brake fluid level warning contact



Wiring Diagram VW NEW BEETLE 2002 - Control unit with display in dash panel insert - handbrake warning switch - brake fluid level warning contact https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
F9Handbrake warning switch
F34Brake fluid level warning contact
J285Control unit with display in dash panel insert
K14Handbrake warning lamp
K118Brake system warning lamp
T1010-pin connector, orange, connector point, electronics box, in plenum chamber, left
T10d10-pin connector, white, connector point, electronics box, in plenum chamber, left
T3232-pin connector, blue, on dash panel insert
T32a32-pin connector, green, on dash panel insert
  12 Earth point, in engine compartment, left
  42 Earth point, next to steering column
  81 Earth connection -1-, in dash panel wiring harness
  85 Earth connection -1-, in engine compartment wiring harness
  131 Earth connection -2-, in engine compartment wiring harness
  135 Earth connection -2-, in dash panel wiring harness
  D55 Connection (brake wear indicator, left), in engine compartment wiring harness
*Left-hand drive models only
Right-hand drive models only

Wiring Diagram VW NEW BEETLE 2002 - Control unit with display in dash panel insert - brake lining/pad wear sender - data bus diagnostic interface



Wiring Diagram VW NEW BEETLE 2002 - Control unit with display in dash panel insert - brake lining/pad wear sender - data bus diagnostic interface https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
G34Brake lining/pad wear sender, front left
J285Control unit with display in dash panel insert
J533Data bus diagnostic interface
K47ABS warning lamp
K155Stability program warning lamp, TCS/ESP
T3232-pin connector, blue, on dash panel insert
T32a32-pin connector, green, on dash panel insert
  D55 Connection (brake wear indicator, left), in engine compartment wiring harness
  D56 Connection (brake wear indicator, left), in engine compartment wiring harness
*Output for illumination
