СИСТЕМЫ СИДЕНИЙ

Электросхема привода сидений для Dodge Caravan C/V 2004

Электросхема привода сидений для Dodge Caravan CV 2004 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема привода сидений для Dodge Caravan C/V 2004 - Список элементов:

  • 30a
  • Driver power seat front riser motor
  • Driver power seat horizontal motor
  • Driver power seat rear riser motor
  • Driver power seat recliner motor
  • Driver power seat switch
  • Fwd
  • G300 (at left "b" pillar)
  • G301 (at right "b" pillar)
  • Hot at all times
  • Passenger power seat front riser motor
  • Passenger power seat horizontal motor
  • Passenger power seat rear riser motor
  • Passenger power seat recliner motor
  • Passenger power seat switch
  • Power seat circuit breaker (under driver's seat)
  • Rwd
  • S355 (w/ heated seat)
  • S361 (w/ heated seat)
  • S366 (w/ heated seat)
