VW NEW BEETLE 2001 – Headlights with gas discharge lamps . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2001
  5. >VW NEW BEETLE 2001 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2001 - Vehicle level sender



Wiring Diagram VW NEW BEETLE 2001 - Vehicle level sender https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
G76Vehicle level sender, rear left
G78Vehicle level sender, front left
J567Left gas discharge lamp control unit with HRC
T6g6-pin connector, on vehicle level sender, front left
T6h6-pin connector, on vehicle level sender, rear left
T14c14-pin connector, on left gas discharge lamp control unit
T17a17-pin connector, on left gas discharge lamp control unit
   120 Earth connection -2-, in headlight wiring harness
   184 Earth connection (headlight range control), in engine compartment wiring harness
   N2 Connection -1-, in headlight range adjustment wiring harness
   N3 Connection -2-, in headlight range adjustment wiring harness
   N4 Connection -3-, in headlight range adjustment wiring harness
   N5 Connection -4-, in headlight range adjustment wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Headlights with left gas discharge lamp



Wiring Diagram VW NEW BEETLE 2001 - Headlights with left gas discharge lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
J343Left gas discharge lamp control unit
J567Left gas discharge lamp control unit with HRC
J606Left main/dip beam switch relay
L13Left gas discharge lamp
M1Side light bulb, left
N347Left main/dip beam switch solenoid
S5Fuse in fuse box/relay plate
T10aa10-pin connector, on headlights with left gas discharge lamp
T14c14-pin connector, on left gas discharge lamp control unit
T17a17-pin connector, on left gas discharge lamp control unit
V48Headlight range control motor, left
   125 Earth connection -3-, in headlight wiring harness
   131 Earth connection -2-, in engine compartment wiring harness
   179 Earth connection, in left headlight wiring harness
   A2 Positive (+) connection (15), in dash panel wiring harness
   A20 Connection (15a), in dash panel wiring harness
   A27 Connection (speed signal), in dash panel wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
   C12 Positive (+) connection -1-, in headlight wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Headlights with right gas discharge lamp



Wiring Diagram VW NEW BEETLE 2001 - Headlights with right gas discharge lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J344Right gas discharge lamp control unit
J568Right gas discharge lamp control unit with HRC
J607Right main/dip beam switch relay
L14Right gas discharge lamp
M3Side light bulb, right
N348Right main/dip beam switch solenoid
T10z10-pin connector, on right gas discharge lamp control unit
T10ab10-pin connector, on headlights with right gas discharge lamp
T1616-pin connector, diagnostic connector
T17b17-pin connector, on right gas discharge lamp control unit
V49Headlight range control motor, right
   12 Earth point, in engine compartment, left
   85 Earth connection -1-, in engine compartment wiring harness
   131 Earth connection -2-, in engine compartment wiring harness
   176 Earth connection, in right headlight wiring harness
   240 Earth connection -4-, in headlight wiring harness
   A76 Connection (diagnosis wire K), in dash panel wiring harness
   C16 Connection -2-, in headlight wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Lighting switch - fuses - control unit with display in dash panel insert



Wiring Diagram VW NEW BEETLE 2001 - Lighting switch - fuses - control unit with display in dash panel insert https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E1Lighting switch
E4Headlight dipper/flasher switch
J285Control unit with display in dash panel insert
K1Main beam warning lamp
S18Fuse in relay plate fuse box
S19Fuse in relay plate fuse box
S20Fuse in relay plate fuse box
S21Fuse in relay plate fuse box
S22Fuse in relay plate fuse box
S223Fuse in fuse box
T1212-pin connector, column switch trim
T1717-pin connector, on lighting switch
T3232-pin connector, blue, on dash panel insert
T32a32-pin connector, green, on dash panel insert
   A43 Connection (57L), in dash panel wiring harness
   A44 Connection (57R), in dash panel wiring harness
   A84 Connection (58L), in dash panel wiring harness
   A85 Connection (58R), in dash panel wiring harness
   B141 Positive (+) connection -1- (56a), in interior wiring harness
   B142 Positive (+) connection -2- (56a), in interior wiring harness
   B167 Connection (56b), in interior wiring harness
   B251 Connection (fault message), in interior wiring harness
