VW NEW BEETLE 2001 – Daylight driving lights . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2001
  5. >VW NEW BEETLE 2001 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2001 - Dash panel insert - turn signal switch - headlight dip and flasher switch - parking light switch



Wiring Diagram VW NEW BEETLE 2001 - Dash panel insert - turn signal switch - headlight dip and flasher switch - parking light switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
DIgnition/starter switch
E2Turn signal switch
E3Hazard warning light switch
E4Headlight dipper/flasher switch
E19Parking light switch
J285Control unit with display in dash panel insert
K1Main beam warning lamp
K13Rear fog light warning lamp
K65Left turn signal warning lamp
K94Right turn signal warning lamp
S22Fuse in relay plate fuse box
S223Fuse in fuse holder
T88-pin connector
T1212-pin connector
T3232-pin connector, blue
   A5 Positive (+) connection (right turn signal), in dash panel wiring harness
   A6 Positive (+) connection (left turn signal), in dash panel wiring harness
   A51 Connection (56), in dash panel wiring harness
   A83 Connection (day driving lights), in dash panel wiring harness
   A84 Connection (58L), in dash panel wiring harness
   A85 Connection (58R), in dash panel wiring harness
   A88 Connection (RFL), in dash panel wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Front left bulbs - front right bulbs



Wiring Diagram VW NEW BEETLE 2001 - Front left bulbs - front right bulbs https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
L1Twin filament bulb/sealed beam insert, left
L2Twin filament bulb/sealed beam insert, right
M1Side light bulb, left
M3Side light bulb, right
M5Turn signal bulb, front left
M7Turn signal bulb, front right
M18Side turn signal bulb, left
M19Side turn signal bulb, right
S18Fuse in relay plate fuse box
S19Fuse in relay plate fuse box
S20Fuse in relay plate fuse box
S21Fuse in relay plate fuse box
   12 Earth point, in engine compartment, left
   179 Earth connection, in left headlinght wiring harness
   B166 Connection (56a), in interior wiring harness
   B167 Connection (56b), in interior wiring harness
   C28 Connection -1- (56b), in headlight wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Lighting switch - rear fog light switch - switches and instruments lightning control



Wiring Diagram VW NEW BEETLE 2001 - Lighting switch - rear fog light switch - switches and instruments lightning control https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
E1Lighting switch
E18Rear fog light switch
E20Switches and instruments - lighting control
L9Lighting switch light bulb
S36Fuse -36- in fuse box
T6c6-pin connector
T1818-pin connector
   81 Earth connection -1-, in dash panel wiring harness
   501 Screw connection -2- (30), on relay plate
   A4 Positive (+) connection (58b), in dash panel wiring harness
   A32 Positive connection (30), in dash panel wiring harness
   A80 Connection -1- (X), in dash panel wiring harness
   A83 Connection (day driving lights), in dash panel wiring harness
   A116 Connection -2- (58d), in dash panel wiring harness
   B167 Connection (56b), in interior wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Brake light - rear fog light - left reversing light - left tail light - rear right turn signal



Wiring Diagram VW NEW BEETLE 2001 - Brake light - rear fog light - left reversing light - left tail light - rear right turn signal https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
FBrake light switch
F4Reversing light switch
L46Rear fog light bulb, left
M6Turn signal bulb, rear left
M16Reversing light bulb, left
M21Brake and tail light bulb, left
M25High level brake light bulb (32 LED's)
T55-pin connector, black, left C-pillar coupling station
T1010-pin connector, orange, in protective housing for connectors, left in plenum chamber
   98 Earth connection, in tailgate/boot lid wiring harness
   199 Earth connection -3-, in dash panel wiring harness
   A6 Positive (+) connection (left turn signal), in dash panel wiring harness
   A18 Connection -54-, in dash panel wiring harness
   W1 Positive (+) connection (54), in rear wiring harness
   W3 Connection in rear wiring harness
   W28 Positive connection -2- (54), in tail light wiring harness

Wiring Diagram VW NEW BEETLE 2001 - brake light - right reversing light - right tail light - glove compartment light - registration plate light - rear right turn signal



Wiring Diagram VW NEW BEETLE 2001 - brake light - right reversing light - right tail light - glove compartment light - registration plate light - rear right turn signal https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
M8Turn signal bulb, rear right
M17Reversing light bulb, right
M22Brake and tail light bulb, right
S3Fuse in relay plate fuse box
S4Fuse in relay plate fuse box
T22-pin connector, on left in luggage compartment
XNumber plate light
   57 Earth point, left rear pillar
   199 Earth connection -3-, in dash panel wiring harness
   218 Earth connection -1-, in tailgate/boot lid wiring harness
   A5 Positive (+) connection (right turn signal), in dash panel wiring harness
   W11 Connection (58), in tailgate/boot lid wiring harness
