VW NEW BEETLE 2001 – Radiator fan, 2-speed, 1.8 l/110 kW Motronic, engine codes AWU (coolant system 8Z5/8Z7) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW NEW BEETLE
  4. >VW NEW BEETLE 2001
  5. >VW NEW BEETLE 2001 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW NEW BEETLE 2001 - Radiator fan control unit - radiator fan thermo-switch



Wiring Diagram VW NEW BEETLE 2001 - Radiator fan control unit - radiator fan thermo-switch https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
DIgnition/starter switch
F18Radiator fan thermo-switch
J293Radiator fan control unit, in engine compartment, front left
S5Fuse in fuse box
S16Fuse in fuse box
S164Fuse -3- (30), in fuse box/battery
S180Fuse -8- (30), in fuse box/battery
T33-pin connector, on battery fuse box
T4a4-pin connector
T14b14-pin connector
   501 Screw connection -2- (30), on relay plate
   A2 Positive (+) connection (15), in dash panel wiring harness
   A20 Connection (15a), in dash panel wiring harness
   A32 Positive (+) connection (30), in dash panel wiring harness
   A40 Positive (+) connection -1- (30), in dash panel wiring harness
   B236 Positive (+) connection -6- (30a), in interior wiring harness
   K21 Connection -1-, in radiator fan wiring harness

Wiring Diagram VW NEW BEETLE 2001 - Radiator fan control unit - radiator fan - continued coolant circulation pump



Wiring Diagram VW NEW BEETLE 2001 - Radiator fan control unit - radiator fan - continued coolant circulation pump https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J293Radiator fan control unit, in engine compartment, front left
T3a3-pin connector, in engine compartment, front right
T3b3-pin connector, in engine compartment, front left
T4a4-pin connector, on radiator fan control unit
T4k4-pin connector, in engine compartment, near continued coolant circulation pump
T14b14-pin connector, on radiator fan control unit
V7Radiator fan
V35Radiator fan, right
V51Continued coolant circulation pump
   12 Earth point, in engine compartment, left
   193 Earth connection -1-, in radiator fan wiring harness
   C11 Connection, in radiator fan wiring harness
   K21 Connection -1-, in radiator fan wiring harness
