VW NEW BEETLE 2001 – Air conditioner, 2.3 litre Motronic/125 kW, engine codes AQN . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW NEW BEETLE 2001 - Fresh air blower switch - fresh air/air recirculating flap switch - fresh air blower - fresh/recirculating air flap control motor

D	Ignition/starter switch
E9	Fresh air blower switch
E159	Fresh air/air recirculating flap switch
K114	Fresh air/air recirculation warning lamp
L16	Fresh air controls light bulb
N24	Fresh air blower with overheating fuse series resistor
S5	Fuse in fuse box
S225	Fuse in fuse box
T4c	4-pin connector
T6d	6-pin connector
T8b	8-pin connector
T10j	10-pin connector, behind dash panel, centre
V2	Fresh air blower
V154	Fresh/recirculating air flap control motor
44	Earth point, lower part of left A-pillar
162	Earth connection, in blower motor wiring harness
503	Screw connection (75x), on relay plate
A2	Positive (+) connection (15), in dash panel wiring harness
A4	Positive (+) connection (58b), in dash panel wiring harness
A20	Connection (15a), in dash panel wiring harness
L45	Connection, in air conditioner controls wiring harness
L66	Connection, in heater blower wiring harness

E35	Air conditioner switch
F163	Air conditioner shut-off thermo-switch
G17	Ambient temperature sensor
G65	High pressure sender
J220	Motronic control unit, in plenum chamber, centre
J293	Radiator fan control unit, in engine compartment, front left
K84	Air conditioning system warning lamp
T8b	8-pin connector
T4a	4-pin connector, on radiator fan control unit
T10	10-pin connector, orange, in protective housing for connectors, in plenum chamber, left
T10j	10-pin connector, behind dash panel, centre
T14	14-pin connector, in engine compartment
T14b	14-pin connector, on radiator fan control unit
193	Earth connection -1-, in coolant fan wiring harness
L9	Connection -1-, in air conditioner wiring harness
L45	Connection, in air conditioner controls wiring harness

A	Battery
D	Ignition/starter switch
J293	Radiator fan control unit, in engine compartment, front left
N25	Air conditioning system magnetic coupling
S16	Fuse in relay plate fuse box
S177	Fuse -5- (30), in battery fuse box
T2b	2-pin connector, in engine compartment
T4a	4-pin connector, on radiator fan control unit
T4b	4-pin connector, on radiator fan
T4g	4-pin connector, in engine compartment, near alternator
T14b	14-pin connector, on radiator fan control unit
V7	Radiator fan
V51	Continued circulation of coolant pump
12	Earth point, in engine compartment, left
193	Earth connection -1-, in coolant fan wiring harness
501	Screw connection -2- (30), on relay plate
A32	Positive (+) connection (30), in dash panel wiring harness
A40	Positive (+) connection -1-, (30), in dash panel wiring harness
