| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| D | Ignition/starter switch |
| J59 | X contact relief relay |
| S162 | Fuse -1- (30), in fuse box/battery |
| S163 | Fuse -2- (30), in fuse box/battery |
| S176 | Fuse -4- (30), in fuse box/battery |
| S177 | Fuse -5- (30), in fuse box/battery |
| T4 | 4-pin connector, in protective housing in engine compartment, rear |
| T6 | 6-pin connector, brown, connector point, electronics box, in plenum chamber, left |
| 500 | Screw connection -1- (30), on relay plate |
| 501 | Screw connection -2- (30), on relay plate |
| 502 | Screw connection (30a), on relay plate |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A41 | Positive (+) connection (50), in dash panel wiring harness |
| D | Ignition/starter switch |
| J220 | Motronic control unit, in plenum chamber, centre |
| N152 | Ignition transformer |
| P | Spark plug connector |
| Q | Spark plugs |
| S10 | Fuse in fuse box |
| S229 | Fuse in fuse box |
| T4j | 4-pin connector, on ignition transformer |
| T6 | 6-pin connector, brown, connector point, electronics box, in plenum chamber, left |
| T14 | 14-pin connector, in engine compartment |
| T80 | 80-pin connector |
| 10 | Earth point, in plenum chamber |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| A2 | Positive (+) connection (15), in dash panel wiring harness |
| A104 | Positive (+) connection -2- (15), in dash panel wiring harness |
| F60 | Idling switch |
| G2 | Coolant temperature sender |
| G40 | Hall sender |
| G62 | Coolant temperature sender |
| G69 | Throttle valve potentiometer |
| G88 | Throttle valve positioner potentiometer |
| J220 | Motronic control unit, in plenum chamber, centre |
| J338 | Throttle valve control unit |
| T8 | 8-pin connector |
| T14 | 14-pin connector, in engine compartment |
| T80 | 80-pin connector |
| V60 | Throttle valve positioner |
| 220 | Earth connection (sender earth), in engine wiring harness |
| D147 | Connection (rear left speed sensor), in engine compartment wiring harness |
| * | Only models without cruise control system |
| G28 | Engine speed sender |
| G61 | Knock sensor I |
| G66 | Knock sensor II |
| J217 | Automatic gearbox, in plenum chamber, centre |
| J220 | Motronic control unit, in plenum chamber, centre |
| T3a | 3-pin connector, near intake manifold |
| T3b | 3-pin connector, near intake manifold |
| T3c | 3-pin connector, near intake manifold |
| T10 | 10-pin connector, orange, connector point, electronics box, in plenum chamber, left |
| T10d | 10-pin connector, white |
| T68 | 68-pin connector, on automatic gearbox control unit |
| T80 | 80-pin connector |
| 220 | Earth connection (sender earth), in engine wiring harness |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| * | Compressor switch-off |
| ** | Air conditioner 'ready' connection |
| --- | Only models with automatic gearbox |
| J220 | Motronic control unit, in plenum chamber, centre |
| G108 | Lambda probe II |
| N30 | Injector, cylinder 1 |
| N31 | Injector, cylinder 2 |
| N32 | Injector, cylinder 3 |
| N33 | Injector, cylinder 4 |
| N79 | Heater element (crankcase breather) |
| T4a | 4-pin connector, in protective housing in engine compartment, rear |
| T6 | 6-pin connector, brown, connector point, electronics box, in plenum chamber, left |
| T10 | 10-pin connector, orange, connector point, electronics box, in plenum chamber, left |
| T10d | 10-pin connector, in cable channel left in engine compartment |
| T14 | 14-pin connector, in engine compartment |
| T80 | 80-pin connector |
| D140 | Connection (injectors), in engine prewiring wiring harness |
| E30 | Connection (87a), in engine wiring harness |
| J220 | Motronic control unit, in plenum chamber, centre |
| N112 | Secondary air inlet valve |
| S232 | Fuse in fuse box |
| S234 | Fuse in fuse box |
| S243 | Fuse in fuse box |
| T3d | 3-pin connector |
| T6 | 6-pin connector, brown, connector point, electronics box, in plenum chamber, left |
| T10 | 10-pin connector, orange, connector point, electronics box, in plenum chamber, left |
| T10h | 10-pin connector, in cable channel left in engine compartment |
| T80 | 80-pin connector |
| V144 | Fuel system diagnostic pump |
| 99 | Connection -1- (87), in dash panel wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A100 | Connection -2- (87), in dash panel wiring harness |
| B146 | Connection -1- (87), in interior wiring harness |
| E30 | Connection (87a), in engine wiring harness |
| * | Not all levels of equipment |
| D | Ignition/starter switch |
| G | Fuel gauge sender |
| G6 | Fuel pump (pre-supply pump) |
| G22 | Speedometer sender (hall sender, on gearbox) |
| G32 | Coolant shortage indicator sender |
| G266 | Oil level/oil temperature sender |
| J17 | Fuel pump relay |
| J234 | Airbag control unit |
| S5 | Fuse in fuse box/relay plate |
| S228 | Fuse in fuse box |
| T14 | 14-pin connector, in engine compartment |
| 10 | Earth point, in plenum chamber |
| 135 | Earth connection -2-, in dash panel wiring harness |
| 269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
| 281 | Earth connection -1-, in engine pre-wiring harness |
| 504 | Screw connection -1- (87), on relay plate |
| A2 | Positive (+) connection (15), in dash panel wiring harness |
| A13 | Connection (door contact switch), in dash panel wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| A125 | Connection (crash signal), in dash panel wiring harness |
| F1 | Oil pressure switch |
| G1 | Fuel gauge |
| G3 | Coolant temperature gauge |
| G5 | Rev. counter |
| H11 | Oil pressure warning buzzer |
| J285 | Control unit with display in dash panel insert |
| J533 | Data bus diagnostic interface |
| K2 | Alternator warning lamp |
| K3 | Oil pressure warning lamp |
| K38 | Oil level warning lamp |
| T14 | 14-pin connector, in engine compartment |
| T16 | 16-pin connector, diagnostic connector |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32a | 32-pin connector, green, on dash panel insert |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
