Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Dodge Charger SRT-8 2014

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag (1 из 3) для Dodge Charger SRT-8 2014

Электросхема подушек безопасности SRS AirBag (1 из 3) для Dodge Charger SRT-8 2014 - Список элементов:

• (base of left "b" pillar) driver seat belt retractor tensioner
• (base of right "b" pillar) passenger seat belt retractor tensioner
• (pins: 1 to 53 not used)
• 58b
• 65b
• Can c (+)
• Can c (-)
• Computer data lines system
• D64
• D65
• Drv seat belt buckle sw gnd
• Drv seat belt buckle sw sns
• Drv seat belt retract tensioner line 1
• Drv seat belt retract tensioner line 2
• Drv seat belt retractor tensioner line 1
• Drv seat belt retractor tensioner line 2
• Drv seat belt retrct tensioner line 1
• Drv seat belt retrct tensioner line 2
• Drv seat pos sens data
• Drv seat pos sens volt
• F929
• F945
• Fd ign sw output
• Fuse 10a
• Hot w/ run relay energized
• Hot w/ run/start relay energized
• I470
• I600
• I650
• Ign run/strt ctrl output
• Left "b" pillar)
• Left curtain squib 1 line 1
• Left curtain squib 1 line 2
• Left pedestrian impact sens gnd
• Left pedestrian impact sens sig
• Left seat thorax squib 1 line 1
• Left seat thorax squib 1 line 2
• Left side imapct sens 1 gnd
• Left side imapct sens 1 sig
• Left side impact press sens gnd
• Left side impact press sens sig
• Left side impact pressure sensor (center of left front door)
• Left side impact sensor 1 (base of
• Lf impact sens gnd
• Lf impact sens sig
• Lt sde impt sens 1 gnd
• Lt sde impt sens 1 sig
• Occupant detection sensor (in front passenger's seat cushion)
• Occupant restraint controller module (in center console)
• Pass seat belt buckle sw gnd
• Pass seat belt buckle sw sns
• Pass seat belt retract tensioner line 1
• Pass seat belt retract tensioner line 2
• Pass seat belt retractor tensioner line 1
• Pass seat belt retractor tensioner line 2
• Pass seat belt retrct tensioner line 2
• Pass seat occp dtctr rtn
• Pass seat occp dtctr sig
• Pass seat pos sens data
• Pass seat pos sens volt
• Pass seat position sens data
• Pass seat position sens volt
• Passenger seat track position sensor
• R13
• R130
• R14
• R140
• R15
• R150
• R16
• R160
• R170
• R171
• R172
• R173
• R261
• R262
• R263
• R264
• R283
• R284
• R503
• R504
• R505
• R506
• R53
• R54
• R55
• R56
• R57
• R58
• R59
• R60
• R79
• R80
• R81
• R82
• Rear power distribution center (center rear of luggage compt)
• Rf impact sens gnd
• Rf impact sens sig
• Right curtain squib 1 line 1
• Right curtain squib 1 line 2
• Right pedestrian impact sens gnd
• Right pedestrian impact sens sig
• Right seat thorax squib 1 line 2
• Right side impact press sens gnd
• Right side impact press sens sig
• Right side impact pressure sensor (center of right front door)
• Right side impact sens 1 gnd
• Right side impact sens 1 sig
• Right side impact sensor 1 (base of right "b" pillar)
• Rt sde impt sens 1 gnd
• Rt sde impt sens 1 sig
• Side impt prss sens gnd
• Side impt prss sens sig
• Tensioner line 1 pass seat belt retrct

Электросхема подушек безопасности SRS AirBag (2 из 3) для Dodge Charger SRT-8 2014

Электросхема подушек безопасности SRS AirBag (2 из 3) для Dodge Charger SRT-8 2014 - Список элементов:

• (left front corner of engine compt) left front impact sensor
• (outer edge of driver's seat back) left side thorax air bag
• (outer edge of passenger's seat back) right side thorax air bag
• (right front corner of engine compt) right front impact sensor
• (under driver's seat) driver seat track position sensor
• Driver seat belt buckle tensioner (base of driver seat belt buckle assembly)
• Driver seat belt switch (integral to driver seat belt buckle assembly)
• Drv seat belt pret buckle line 1
• Drv seat belt pret buckle line 2
• Drv seat belt sw gnd
• Drv seat belt sw sens
• Drv seat position sens data
• Drv seat position sens volt
• Ft lt impt sens gnd
• Ft lt impt sens sig
• Ft rt impt sens gnd
• Ft rt impt sens sig
• I104
• I1451a
• I1461a
• I251
• I253
• I460
• I470
• Left impact pedestrian sensor (300)
• Left seat thrx squib 1 line 1
• Left seat thrx squib 1 line 2
• Left side curtain air bag (in left roof rail)
• Lt crtn squib 1 line 1
• Lt crtn squib 1 line 2
• Pass seat belt buckle sw gnd
• Pass seat belt buckle sw sns
• Passenger seat belt switch (integral to passenger seat belt buckle assembly)
• Pedestrian impt sens gnd
• Pedestrian impt sens sig
• Right impact pedestrian sensor (300)
• Right side curtain air bag (in right roof rail)
• Rt crtn squib 1 line 1
• Rt crtn squib 1 line 2
• Squib 1 line 1 rt seat thrx
• Squib 1 line 2 rt seat thrx

Электросхема подушек безопасности SRS AirBag (3 из 3) для Dodge Charger SRT-8 2014

Электросхема подушек безопасности SRS AirBag (3 из 3) для Dodge Charger SRT-8 2014 - Список элементов:

• (300) center impact pedestrian sensor
• (300) left pedestrian hood actuator
• (300) right pedestrian hood actuator
• (base of left "c" pillar) left side impact sensor 2
• (base of passenger seat belt buckle assembly) passenger seat belt buckle tensioner
• (base of right "c" pillar) right side impact sensor 2
• (center of dash) g918a
• (right side of dash) passenger air bag squib 1
• C104
• Can c (+)
• Can c (-)
• Center pedes impt sens gnd
• Center pedes impt sens sig
• Center pedestrian impact sens gnd
• Center pedestrian impact sens sig
• Computer data lines system
• Driver air bag squib 1 (in steering wheel)
• Driver air bag squib 2 (in steering wheel)
• Driver knee blocker air bag (lower left side of dash)
• Drv knee blocker
• Drv knee squib line 1
• Drv knee squib line 2
• Drv squib 1 line 1
• Drv squib 1 line 2
• Drv squib 2 line 1
• Drv squib 2 line 2
• Gnd
• I253
• I405
• I470
• Instrument cluster
• Left hood act squib line 1
• Left hood act squib line 2
• Left side impt sens 2 gnd
• Left side impt sens 2 sig
• Lt hood actuator squib line 1
• Lt hood actuator squib line 2
• Lt side impt sens 2 gnd
• Lt side impt sens 2 sig
• Occupant restraint controller module (in center console)
• Pass seat belt pret buckle line 1
• Pass seat belt pret buckle line 2
• Pass squib 1 line 1
• Pass squib 1 line 2
• Pass squib 2 line 1
• Pass squib 2 line 2
• Passenger air bag squib 2 (right side of dash)
• R11
• R17
• R174
• R175
• R176
• R177
• R178
• R179
• R18
• R19
• R20
• R42
• R43
• R44
• R45
• R61
• R62
• R63
• R64
• Red
• Right hood act squib line 1
• Right hood act squib line 2
• Right side impt sens 2 gnd
• Right side impt sens 2 sig
• Rt hood actuator squib line 1
• Rt hood actuator squib line 2
• Rt side impt sens 2 gnd
• Rt side impt sens 2 sig
• Squib line 1
• Squib line 2
• Steering control module (steering column)
• Z918
