Электросхема линии передачи данных CAN для Dodge Caravan SE 2004

Электросхема линии передачи данных CAN для Dodge Caravan SE 2004 - Список элементов:

• (in floor pan track wiring) s302
• (near starter) g101
• A/c-heater control (center of dash)
• A/t
• Adjustable pedals module (near brake light switch)
• Air bag control module (orc) (behind right side of dash)
• Atc
• Auto temp control
• Base
• Body control module (behind left side of dash)
• Cd changer
• Controller anti-lock brake (on right side of transaxle)
• D123
• D15
• D20
• D21
• D25
• Data link connector (below left side of dash)
• Dvd/cd changer
• Flash program
• Flash program enable
• Front control module
• G300 (at left "b" pillar)
• Hot at all times
• Instrument cluster
• Integrated power module (left rear of transaxle)
• Left sliding door control module (in left sliding door, above motor)
• Memory seat/ mirror module (under driver's seat)
• Mtc
• Overhead console (except base)
• Pci bus
• Power liftgate module (mounted on left "d" pillar)
• Powertrain control module (left rear of transaxle)
• Premium
• Ptc 13a
• Radio
• Right sliding door control module (in right sliding door, above motor)
• S111
• S303
• Sci receive
• Sci transmit
• Sentry key remote entry module (skreem) (left side of dash)
• W/ memory
