Электросхемы ПРИВОД СТЕКЛОПОДЪЕМНИКОВ Audi A4 2.0T Avant Quattro 2011

ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников (1 из 2) для Audi A4 2.0T Avant Quattro 2011

Электросхема стеклоподъемников (1 из 2) для Audi A4 2.0T Avant Quattro 2011 - Список элементов:

• Computer data lines system
• Computer data lines system g639 (behind left kick panel)
• Discontinued phased in modification
• Driver window regulator motor
• Driver's door control module (in driver's front door)
• Driver's side fuse panel (behind left end of dash)
• Front passenger window regulator motor
• Front passenger's door control module (in front passenger's front door)
• Fuse 30a
• Fuse carrier
• G638 (behind right kick panel)
• Hot at all times
• Interior lights system
• Luggage compartment relay/fuse carrier (right side of luggage compt)
• Phased in modification
• Right front window regulator switch
• T20f
• T20g
• T27a
• T27c
• T2og
• T32j
• T32l
• T6a0
• T6am
• W/ additional lighting equipment

Электросхема стеклоподъемников (2 из 2) для Audi A4 2.0T Avant Quattro 2011

Электросхема стеклоподъемников (2 из 2) для Audi A4 2.0T Avant Quattro 2011 - Список элементов:

• Child safety button
• Discontinued phased in modification
• Driver's door power window control head
• Interior lights system
• Left front window regulator switch
• Left rear door control module (in left rear door)
• Left rear window regulator motor
• Left rear window regulator switch
• Left rear window switch
• Phased in modification
• Right front window regulator switch
• Right rear door control module (in right rear door)
• Right rear window regulator motor
• Right rear window regulator switch
• Right rear window switch
• T16o
• T16p
• T20h
• T20i
• T27b
• T27d
• T6au
• T6av
• W/ additional lighting equipment
