ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Audi Q5 TDI Premium Plus 2014

Электросхема панели приборов для Audi Q5 TDI Premium Plus 2014 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема панели приборов для Audi Q5 TDI Premium Plus 2014 - Список элементов:

  • (under left front of center console) g687
  • 2.0l turbo
  • 2.0l turbo hybrid
  • 3.0l sc
  • 3.0l turbo diesel
  • Abs indicator lamp
  • Air bag indicator lamp
  • Asr/ esp indicator lamp
  • Brake fluid level warning switch (in master cylinder reservoir)
  • Computer data lines system
  • Engine control module (3.0l turbo diesel: left rear of engine) (except 3.0l turbo diesel: in left plenum chamber)
  • Fuel delivery unit (top of fuel tank)
  • Fuel level sensor
  • Fuse 5a
  • Fuse carrier 2
  • Fuse panel d (right end of dash)
  • G12 (left rear of engine compt)
  • G50 (left "d" pillar)
  • Hot at all times
  • Instrument cluster control module
  • Oil pressure switch (2.0l turbo: front of engine)
  • Oil pressure switch (front of right cylinder bank)
  • Oil pressure switch (top rear of engine)
  • Radio frequency controlled clock receiver
  • Speedometer
  • T105
  • T16b
  • T17c
  • T17g
  • T32b
  • T91
  • T94
  • Tachometer
  • Vehicle electrical system control module (left side of dash)
