Электросхемы ВНЕШНЕЕ ОСВЕЩЕНИЕ Dodge Pickup R3500 2010

ВНЕШНЕЕ ОСВЕЩЕНИЕ

Электросхема заднего хода для Dodge Pickup R3500 2010

Электросхема заднего хода для Dodge Pickup R3500 2010 - Список элементов:

38

• 3.7l
• 6.7l
• 7 way trailer tow wiring (at trailer hitch)
• B(+)
• Backup lamp feed
• C206
• C210
• C322
• Can bus 2 (+)
• Can bus 2 (-)
• Can bus(+)
• Can bus(-)
• Circuit board
• Computer data lines system
• D51
• D52
• D64
• D65
• Except 3.7l
• Except 6.7l
• G107 (left side of engine compt)
• G314 (left rear frame rail)
• Hot at all times
• Inside rear- view mirror
• Left backup lamp
• Left tail lamp assembly
• Powertrain control module (right rear of engine compt)
• Right backup lamp
• Right tail lamp assembly
• S120 (left kick panel)
• S309
• S325 (left rear frame rail)
• T42
• Totally integrated power module (left front of engine compt)
• Trans rng c2 sig
• Trans rng c3 sig
• Trans rng c4 sig
• Transmission range sensor (3.7l) transmission solenoid/trs assembly (except 3.7l) (left side of transmission)

Электросхема внешнего освещения (1 из 2) для Dodge Pickup R3500 2010

Электросхема внешнего освещения (1 из 2) для Dodge Pickup R3500 2010 - Список элементов:

79

• (except r1500) s102
• (left rear frame rail) s325
• (left rear frame rail) s352
• 7 way trailer tow wiring (at trailer hitch)
• B(+)
• Backup lamp feed
• Batt fd 5
• C111
• C206
• C210
• C322
• C327
• C328
• C329
• C330
• Can ihs bus (+)
• Can ihs bus (-)
• Circuit board
• Computer data lines system
• D264
• D265
• F941
• Fuse m27 20a
• Fuse m34 15a
• Fuse m38 20a
• Fuse m53 15a
• G104 (left front of engine compt)
• G107 (left side of engine compt)
• G212 (right side of dash)
• G314 (left rear frame rail)
• Gnd
• Haz sw sense
• Haz sw sig
• Hot at all times
• Hot w/ run/ start/relay energized
• Ignition run/st
• Inside rearview mirror
• L160
• L161
• L17
• L217
• L51
• L56
• L60
• L61
• L62
• L63
• L91
• Left backup lamp
• Left front park/ turn lamp
• Left front side marker lamp
• Left rear side marker lamp
• Left tail lamp assembly
• Lf turn sig fd
• Lf turn sig ind
• Lin ccn
• Lr turn sig fd
• Park lamp feed
• Pnk
• Red
• Rf turn sig fd
• Rf turn sig ind
• Right backup lamp
• Right front park/ turn lamp
• Right front side marker lamp
• Right rear side marker lamp
• Right tail lamp assembly
• Rr turn sig fd
• S120 (left kick panel)
• S139
• S205
• S236
• S261
• S309
• S353
• Stp lmp sig
• Tail/ stop/ turn lamp
• Totally integrated power module (left front of engine compt)
• Upper bank switch

Электросхема внешнего освещения (2 из 2) для Dodge Pickup R3500 2010

Электросхема внешнего освещения (2 из 2) для Dodge Pickup R3500 2010 - Список элементов:

70

• (left kick panel) g105
• (left side of dash) g211
• (right side of dash) s216
• 3.7l
• 4.7l & 5.7l
• 6.7l
• Auto stick switch
• B15
• B16
• Batt fd
• Brake provision module (left side of dash)
• Brk sig 1
• Brk sig 2
• C123
• C130
• C206
• C210
• C236
• C322
• C344
• Can bus (+)
• Can bus (-)
• Can ihs bus (+)
• Can ihs bus (-)
• Cargo lamp fd
• Cargo lp rtn
• Center high mounted stop lamp
• Center high mounted stop lamp (aftermarket)
• Center high mounted stop/cargo lamp
• Clearance center lamp (except r1500)
• Cluster
• Computer data lines system
• D64
• D65
• Dim 3
• Dim 3 ip
• Dimmer sig
• Except 6.7l
• G105 (left kick panel)
• G211 (left side of dash)
• G314 (left rear frame rail)
• Gnd
• Hdlp/fog lp sel sw
• Headlamp switch
• Ign rs
• Ign run/start
• Iod fd
• Left clearance lamp 1 (except r1500)
• Left clearance lamp 2 (except r1500)
• Left license lamp
• Lin ccn
• Mlfnct sw rtn
• Pnk
• Powertrain control module (3.7l & 4.7l: rear of engine)
• R1500
• R2500/ r3500
• Red
• Right clearance lamp 1 (except r1500)
• Right clearance lamp 2 (except r1500)
• Right license lamp
• S143
• S214 (left side of dash)
• S235
• S250
• S251
• S346
• Stop lamp switch (on brake pedal support)
• Stop lt sig
• Stp lmp sig
• Wireless ignition node

Электросхема розетки подключения прицепа для Dodge Pickup R3500 2010

Электросхема розетки подключения прицепа для Dodge Pickup R3500 2010 - Список элементов:

54

• 5.7l crew cab)
• 7-way trailer tow wiring (at trailer hitch)
• A115
• A903
• B(+)
• B40
• Backup lamps circuit
• Batt fd
• Brake provision module (left side of dash)
• C111
• C210
• C321
• C322
• C344
• Can bus 2 (+)
• Can bus 2 (-)
• Center high mounted stop lamp (aftermarket)
• Center high mounted stop/ cargo lamp
• Circuit board
• Computer data lines system
• Ctrl rt ttow rly
• D51
• D52
• Elec brk fd
• Fuse j2 30a
• Fuse j9 30a
• Fuse m27 20a
• Fuse m53 15a
• G105 (left kick panel)
• G211
• G314 (left rear frame rail)
• Gnd
• Hot at all times
• Hot w/ run/ start relay energized
• Ign rs
• Itbm brake provision module
• L51
• L56
• L655
• L656
• L678
• Lmp sig ttow prk
• S143
• S205
• S214 (left side of dash)
• Stop lamp switch (on brake pedal support)
• Stop lp sig
• Stp lmp sig
• Totally integrated power module (left front of engine compt)
• Trailer tow module
• Ttow rly ctrl lt
• Wireless ignition node
• Z905
• Z914
