Электросхема стеклоочистителя, дворников и омывателя для Dodge Pickup R3500 2010

Электросхема стеклоочистителя, дворников и омывателя для Dodge Pickup R3500 2010 - Список элементов:

• (left kick panel) g105
• 87a
• Abmt/temp fcm ssr rtn 1
• Ambient air temperature sensor (left front of engine compt)
• Batt fd
• Bus (-) can ihs
• Can ihs bus (+)
• Circuit board
• Cluster
• Computer data lines system
• D264
• D265
• Front washer fluid level sensor
• Front washer pump relay
• Front wiper motor
• Ft wsh mtr ctrl
• Fuse m20 25a
• Fuse m32 20a
• G107 (left side of engine compt)
• G306
• G931
• Gnd
• Hi spd fd ft wpr mtr
• Hood ajar switch (if equipped) (left front of engine compt)
• Hot at all times
• Ihs can bus (+)
• Ihs can bus (-)
• Lin ccn
• Lo spd fd ft wpr mtr
• Lo wsh sw snse
• Prk sig ft wpr mtr
• Rear wiper relay
• Rly ctrl wpr on/off
• Rr wsh ctrl
• S194 (left front of engine compt)
• Sccm multi-function switch
• Sig to bcm ft wpr wsh
• Sw snse lo wsh
• Totally integrated power module (left front of engine compt)
• W10
• W20
• Windshield washer pump (left front of engine compt)
• Wiper high/low relay
• Wiper on/off relay
• Wpr hi/lo rly ctrl
• Wsh pmp mtr fd
