Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Dodge Pickup R3500 2010

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag для Dodge Pickup R3500 2010

Электросхема подушек безопасности SRS AirBag для Dodge Pickup R3500 2010 - Список элементов:

• (center front of body) g313
• (left front door)
• (left front of vehicle) (r1500) left front impact sensor
• (r1500 only)
• (r1500) driver seat belt retractor tensioner
• (r1500) passenger seat belt retractor tensioner
• (right front of vehicle) (r1500) right front impact sensor
• C100
• C101
• C203
• C210
• C236
• C301
• C304
• C311
• Can bus (+)
• Can bus (-)
• Can bus2(+)
• Can bus2(-)
• Circuit board run/start
• Clock spring
• Cluster
• Computer data lines system
• D51
• D52
• Driv buckle(+)
• Driv buckle(-)
• Driv squib1(+)
• Driv squib1(-)
• Driv squib2(+)
• Driv squib2(-)
• Driv sw(+)
• Driv sw(-)
• Driver air bag squib 1
• Driver air bag squib 2
• Driver seat belt buckle switch
• F100
• F201
• Fuse m45 10a
• Gnd
• Hot at all times
• Hot w/ run relay energized
• Ign run only
• Impact
• Impact snsr(+)
• Impact snsr(-)
• Impact snsr1(+)
• Impact snsr1(-)
• Impact snsr2(+)
• Impact snsr2(-)
• Left side curtain air bag
• Left side impact pressure sensor
• Left side impact sensor 1
• Left side impact sensor 2
• Lt squib1(+)
• Lt squib1(-)
• Occupant restraint controller module (center front of body)
• Pass buckle(+)
• Pass buckle(-)
• Pass squib1(+)
• Pass squib1(-)
• Pass squib2(+)
• Pass squib2(-)
• Passenger air bag squib 1
• Passenger air bag squib 2
• R13
• R14
• R15
• R16
• R42
• R43
• R44
• R45
• R53
• R54
• R55
• R56
• R57
• R59
• R61
• R62
• R63
• R64
• R79
• R80
• R81
• R82
• Red
• Right side curtain air bag
• Right side impact pressure sensor
• Right side impact sensor 1
• Right side impact sensor 2
• Rt squib1(+)
• Rt squib1(-)
• Run/start
• Snsr1(+)
• Snsr1(-)
• Snsr2(+)
• Snsr2(-)
• Steering control module
• Tan
• Totally integrated power module (left front of engine compt)
• Z913
