Электросхемы БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ Porsche 911 Carrera S 2009

БЛОК ПРЕДОХРАНИТЕЛЕЙ И РЕЛЕ

Электросхема блока предохранителей и реле (1 из 4) для Porsche 911 Carrera S 2009

Электросхема блока предохранителей и реле (1 из 4) для Porsche 911 Carrera S 2009 - Список элементов:

• (not used)
• Ashtray lighting
• Ask amplifier
• Battery
• Bose amplifier
• Bose subwoofer
• Cigar lighter
• Convertible
• Convertible top control unit
• Coupe
• Current distributor (behind right side of dash)
• Driver door control unit
• Front end control unit
• Fuse f1 30a
• Fuse f1 80a
• Fuse f10 15a
• Fuse f2 15a
• Fuse f2 30a
• Fuse f3 15a
• Fuse f3 30a
• Fuse f3 70a
• Fuse f4 150a
• Fuse f4 25a
• Fuse f4 30a
• Fuse f5 15a
• Fuse f5 50a
• Fuse f6 15a
• Fuse f7 15a
• Fuse f8 7.5a
• Fuse f8 70a
• Fuse f9 25a
• Fuses holder a
• Fuses holder e
• Gp3 (left side of support frame)
• Gp4 (center of support frame)
• Interior lights system
• Left power seat control unit
• Left power seat switch
• Left rear power window
• Left seat width adjustment switch
• Package tray plug socket
• Passenger door control unit
• Plug socket 2
• Psm control unit
• Rear control unit
• Red
• Right power seat control unit
• Right rear power window
• Right seat width adjustment switch
• Sun roof propelled
• To fuse f1 fuse holder d (diagram 4 of 4)
• To fuse f6 (diagram 2 of 4)
• To fuse f9 current distributor (diagram 2 of 4)
• To fuse f9 fuse holder d (diagram 4 of 4)
• Vehicle electrical system control unit
• W/ memory
• W/o memory

Электросхема блока предохранителей и реле (2 из 4) для Porsche 911 Carrera S 2009

Электросхема блока предохранителей и реле (2 из 4) для Porsche 911 Carrera S 2009 - Список элементов:

• (not used)
• Alarm siren
• B+ plug socket (near right side of transmission)
• Climatronic control unit
• Combined steering wheel module
• Cooling water fan control unit
• Current distributor (behind right side of dash)
• Diagnosis plug socket
• Engine compartment blower high relay
• Engine compartment blower low relay
• From fuse e4 fuse holder e (diagram 1 of 4)
• From fuse f5 (diagram 1 of 4)
• Front end control unit
• Fuse f1 10a
• Fuse f1 15a
• Fuse f10 30a
• Fuse f2 3a
• Fuse f2 7.5a
• Fuse f2 80a
• Fuse f3 15a
• Fuse f3 3a
• Fuse f4 25a
• Fuse f5 7.5a
• Fuse f6 7.5a
• Fuse f6 80a
• Fuse f7 7.5a
• Fuse f7 80a
• Fuse f8 7.5a
• Fuse f9 7.5a
• Fuse f9 80a
• Fuses holder b
• Fuses holder f
• Generator
• Headlight washing relay
• Heater relay
• Instrument cluster
• Interior sensor
• Maxi fuse 40a
• Midi fuse 80a
• Park assist control unit
• Pdk control unit
• Rear fuses support
• Rear window defogger relay
• Red
• Relay support 1 (left kick panel)
• Relay support 2 (behind left rear seat well)
• Right memory seat
• Right power seat control unit
• Selector lever control unit
• Sports chrono
• Starter
• Tilt sensor
• Tire pressure control unit
• To dme relay (diagram 4 of 4)
• To terminal 15 relay (diagram 3 of 4)
• To terminal 86s relay (diagram 4 of 4)
• Vehicle electrical system control unit
• Weight recognition control unit

Электросхема блока предохранителей и реле (3 из 4) для Porsche 911 Carrera S 2009

Электросхема блока предохранителей и реле (3 из 4) для Porsche 911 Carrera S 2009 - Список элементов:

• (not used)
• Anti- dazzling interior mirror
• Brake pedal switch
• Bridge plug (relay support 1)
• Button module
• Clutch switch
• Combined steering wheel module
• Corner sensitive headlights control unit
• Diagnostic plug socket
• Electronic ignition lock
• Emergency power pin
• Fan backrest motor
• Fan seat motor
• From fuse f6 current distri- butor (diagram 2 of 4)
• From fuse f6 current distributor (diagram 2 of 4)
• Front end control unit
• Fuse f10 25a
• Fuse f2 7.5a
• Fuse f3 10a
• Fuse f4 10a
• Fuse f5 15a
• Fuse f6 15a
• Fuse f7 7.5a
• Fuse f8 10a
• Fuse f9 15a
• Fuses holder c
• Gateway control unit
• Gp7 (under driver's seat)
• Homelink sender
• Left heated spray jet
• Light switch
• Nca
• Pas control unit
• Pasm (damtronic) control unit
• Pasm control unit
• Pdk control unit
• Psm 8 control unit
• Rate of turn sensor
• Rear window module (coupe)
• Red
• Refrigerant sensor
• Right comfort seat
• Right heated spray jet
• Selector lever control unit
• Start lock relay
• Term 15 relay (relay support 1)
• To dme relay (diagram 4 of 4)
• Vehicle electrical system control unit

Электросхема блока предохранителей и реле (4 из 4) для Porsche 911 Carrera S 2009

Электросхема блока предохранителей и реле (4 из 4) для Porsche 911 Carrera S 2009 - Список элементов:

• (coupe)
• (info not available)
• (not used)
• 2a c2
• Air bag control unit
• Air bag off display
• Air cleaner flap (coupe)
• Behind catalytic converter bank 1
• Behind catalytic converter bank 2
• C4 2a
• Camshaft adjustment
• Camshaft sensor 1
• Camshaft sensor 2
• Cooling stop valve
• Cylinder 1-3
• Cylinder 4-6
• Dme control module (coupe)
• Dme control unit
• Dme relay
• Electric fuel pump relay 1
• Engine compartment blower high relay
• Engine compartment blower low relay
• From fuse f4 current distributor (diagram 1 of 4)
• From fuse f4 fuse holder e (diagram 2 of 4)
• From fuse f7 current distri- butor (diagram 2 of 4)
• From fuse f9 fuse holder b (diagram 2 of 4)
• From fuse f9 fuse holder c (diagram 3 of 4)
• Fuse f1 25a
• Fuse f10 15a
• Fuse f2 25a
• Fuse f3 7.5a
• Fuse f4 20a
• Fuse f5 25a
• Fuse f6 25a
• Fuse f7 15a
• Fuse f8 7.5a
• Fuse f9 10a
• Fuses holder d
• Heated oxygen sensor catalytic converter bank 1
• Heated oxygen sensor catalytic converter bank 2
• Hfm5
• Ignition coil cylinder
• Mobile phone
• Oil level sensor
• Pas control unit
• Pcm
• Quantity control valve
• Red
• Relay support 2
• Resonance flap valve
• Spot exhaust valve (coupe)
• Tank leakage diagnostics module
• Tank venting valve
• Telephone hand set
• Television tuner
• Terminal 86s relay (relay support 1)
• Weight recognition control unit
