Электросхемы ПРИВОД ЛЮКА И КРЫШИ Porsche 911 Carrera S 2009

ПРИВОД ЛЮКА И КРЫШИ

Электросхема складной крыши для Porsche 911 Carrera S 2009

Электросхема складной крыши для Porsche 911 Carrera S 2009 - Список элементов:

• Buttn
• Can high
• Can high disp
• Can low
• Can low disp
• Can wake up
• Catch lock
• Computer data lines system
• Conv top lift
• Conv top mtr close
• Conv top mtr up
• Conv top poti +5
• Conv top poti +5v
• Conv top poti gnd
• Conv top poti sig
• Convertible top compartment lid motor
• Convertible top control unit
• Convertible top micro switch
• Convertible top micro-switch compartment lid
• Convertible top sw
• Convertible top/ glass roof switch
• Defogger system
• Fuse f3 30a
• Fuse holder e
• Gnd
• Gp4 (center of support frame)
• Gp8 (left rear of engine compt)
• Hot at all times
• Instrument cluster
• Interior lights system
• Ki 30
• Latch lock drive motor
• Left rear power window
• Left rear side flap
• Lift
• Lift switch
• Light
• Lock switch
• Lower
• Lr side flap down
• Lr side flap extend
• Lr side flap extract
• Lr side flap up
• Lr wind down
• Lr wind status
• Mtr catch lock
• Mtr catch unlk
• Nca
• Park brake
• Power top motor
• Power top potentiometer
• Pwm
• Red
• Right rear power window
• Right rear side flap
• Rr side flap down
• Rr side flap extend
• Rr side flap extract
• Rr side flap up
• Rr wind down
• Rr wind status
• Rr wind up
• Term 30
• Term 31
• Top closed
• Top open
• Top unlk
• Unlock switch

Электросхема привода люка для Porsche 911 Carrera S 2009

Электросхема привода люка для Porsche 911 Carrera S 2009 - Список элементов:

• Can comfort hi
• Can comfort lo
• Close
• Computer data lines system
• Electronic sunroof switch
• Enabling sig
• Fuse f3 30a
• Fuse holder e
• Gp3 (left side of support frame)
• Ground
• Hot at all times
• Lift
• Open
• Power
• Rear control unit
• Sliding roof enabling sig
• Sunroof drive

схема крыши тарга для Porsche 911 Carrera S 2009

схема крыши тарга для Porsche 911 Carrera S 2009 - Список элементов:

• Bridge plug
• Can high comfort
• Can low comfort
• Close mtr
• Close roller blind
• Computer data lines system
• Electronics terminal 30
• Electronics terminal 31
• Film capacitor
• Fuse f5 7.5a
• Fuse f6 15a
• Fuse f7 30a
• Fuse holder b
• Fuse holder c
• Fuse holder e
• Glass roof motor 1 close +
• Glass roof motor 1 open +
• Glass roof motor 2 close +
• Glass roof motor 2 open +
• Gp8 (left rear of engine compt)
• Hall sens gnd mtr 1
• Hall sens sig motor 1
• Hall sensor
• Hall sensor +
• Hall sensor -
• Hot at all times
• Left targa flap lights
• Locked
• Micro sw closing aid lock
• Micro sw closing aid primary detent
• Micro sw closing aid unlock
• Micro sw roof closed
• Mtr normal running
• Mtr rtn
• Nca
• Normal running closing aid
• Open mtr
• Open roller blind
• Power distribution system
• Primary detent
• Rear control unit
• Rear window wiper
• Red
• Right targa flap lights
• Roller blind
• Rtn closing aid
• Sig roof closed
• Sply hall sens motor 1
• Targa light
• Targa roof microswitch
• Targa roof system
• Targa roof system closing aid
• Targa roof system control unit
• Targa roof system drive motor 1
• Targa roof system drive motor 2
• Terminal 30
• Terminal 31
• Unlocked
