СИСТЕМА УПРАВЛЕНИЯ ДВИГАТЕЛЯ
3.6L
3.6L, Электросхема системы управления двигателем (1 из 4) для Porsche 911 Carrera S 2009
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO
3.6L, Электросхема системы управления двигателем (1 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (hfm1)
- (info not available)
- +5v vehicle
- Behind catalytic converter bank 1
- Behind catalytic converter bank 2
- Bridge plug (relay support 1)
- Can high
- Can low 1
- Clutch interlock switch (top of clutch pedal assembly)
- Clutch switch
- Computer data lines system
- Cooling fans system
- Cooling water
- Dme control unit (left front of engine compt)
- Dme relay
- Dmtl-heizung
- Electronic mufflers system
- Fuel pump
- Fuel pump 1
- Fuse f3 7.5a
- Fuse f4 20a
- Fuse f5 25a
- Fuse f6 25a
- Fuse f7 15a
- Fuse f8 7.5a
- Fuses holder d
- Gnd
- Gp4 (center of support frame)
- Gp9 (right rear of engine compt)
- Ground
- Heated oxygen 1
- Heated oxygen 2
- Hi rly ctrl
- Hot at all times
- Lo rly ctrl
- Lsf heater nk
- Lsf heater nk b2
- Lsf sig
- Lsf signal nk b1
- Lsu comp
- Lsu ground vk b1
- Lsu heater
- Lsu pumping
- Pas control unit (behind left side of dash)
- Pdk control unit
- Pedal sens
- Power distribution system
- Pwg +5v 1
- Pwg +5v poti 2
- Quantity control valve
- Sensor ground
- Signal, maf
- Sports exhaust
- Starter lock
- Starter relay
- Starting/charging system
- Tailgate sw
- Tank leakage
- Tank leakage diagnostics module
- Terminal 15
- Terminal 30
- Terminal 31
- Terminal 87
3.6L, Электросхема системы управления двигателем (2 из 4) для Porsche 911 Carrera S 2009
3.6L, Электросхема системы управления двигателем (2 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (convertible) fuel pump control unit
- (left rear of engine compt) gp8
- (left side of support frame) gp3
- (side of expansion tank) cooling water level switch
- (w/ electronic fuel pump control unit) fuel pump level sensor
- Air cleaner
- Air conditioning system
- Camshaft adjustment 1 (cyl 1-3)
- Camshaft adjustment 2 (cyl 4-6)
- Clock sig h-
- Fuel level grd
- Fuel level sens
- Gnd
- Heated oxygen sensor catalytic converter bank 1
- Heated oxygen sensor catalytic converter bank 2
- Instrument cluster
- Knock sensor 1 (engine block)
- Knock sensor 2 (engine block)
- Mass air fuel sensor
- Measuring sig
- Nca
- Oil level sensor
- Pedal value sensor (behind accelerator pedal)
- Pump
- Pump +
- Pump -
- Pump current
- Pwm
- Resistor rt
- Sports exhaust system solenoid 1
- Sports exhaust system solenoid 2
- Tank venting valve
- Temp sens
- Term 15
- Terminal 31
- Terminal 87
- U battery h+
- Voltage re+
3.6L, Электросхема системы управления двигателем (3 из 4) для Porsche 911 Carrera S 2009
3.6L, Электросхема системы управления двигателем (3 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (relay support 1) (convertible) electric fuel pump relay 1
- (top of engine)
- Air bag control unit (below center console)
- Air cleaner
- Camshaft adjustment
- Camshaft sensor (left rear & right front of engine)
- Crash input
- Crash output
- Cylinder 1-
- Cylinder 3
- Cylinder 4
- Cylinder 5
- Cylinder 5-
- Dme control unit (left front of engine compt)
- Engine speed +
- Engine speed -
- Fuse f1 25a
- Fuses holder d
- Generator
- Gnd
- Hallgeber 1
- Hallgeber 2
- Hot at all times
- Lift valve control
- Nca
- Oil pressure
- Oil pressure resonance
- Resonance flap valve
- Shield
- System starting/charging
- Throttle valve
3.6L, Электросхема системы управления двигателем (4 из 4) для Porsche 911 Carrera S 2009
3.6L, Электросхема системы управления двигателем (4 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (intake manifold) throttle valve
- (right side of engine) oil pressure sensor w/ temperature
- (top of cylinders)
- (top of cylinders) fuel injectors
- +5v
- Camshaft adjuster b1
- Camshaft b2
- Control valve
- Cooling water
- Cooling water sensor (in water box)
- Cylinder 1
- Cylinder 2
- Cylinder 6
- Dme control unit (left front of engine compt)
- Electronic mufflers system
- Engine compt
- Exhaust system
- Gp9 (right rear of engine compt)
- Ground, sensors
- High pressure rail sensor
- High pressure sens
- Ignition coil cylinder
- Injector, cylinder 1+
- Injector, cylinder 1-
- Injector, cylinder 2+
- Injector, cylinder 3+
- Injector, cylinder 3-
- Injector, cylinder 4+
- Injector, cylinder 4-
- Injector, cylinder 5+
- Injector, cylinder 6+
- Injector, cylinder 6-
- Nca
- Ntc
- Ntc engine compartment temperature sensor (middle of engine)
- Oil pressure sens
- Oil temp sens
- P-out
- Plug
- Resonance flap
- Sensor gnd
- Shield
- Sig
- Spark plug
- Tank valve
- Terminal 31
- Throttle valve
- Valve control b1
- Valve control b2
3.8L
3.8L, Электросхема системы управления двигателем (1 из 4) для Porsche 911 Carrera S 2009
3.8L, Электросхема системы управления двигателем (1 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (hfm1)
- (info not available)
- +5v vehicle
- Behind catalytic converter bank 1
- Behind catalytic converter bank 2
- Bridge plug (relay support 1)
- Can high
- Can low 1
- Clutch interlock switch (top of clutch pedal assembly)
- Clutch switch
- Computer data lines system
- Cooling fans system
- Cooling water
- Dme control unit (left front of engine compt)
- Dme relay
- Dmtl-heizung
- Electronic mufflers system
- Fuel pump
- Fuel pump 1
- Fuse f3 7.5a
- Fuse f4 20a
- Fuse f5 25a
- Fuse f6 25a
- Fuse f7 15a
- Fuse f8 7.5a
- Fuses holder d
- Gnd
- Gp4 (center of support frame)
- Gp9 (right rear of engine compt)
- Ground
- Heated oxygen 1
- Heated oxygen 2
- Hi rly ctrl
- Hot at all times
- Lo rly ctrl
- Lsf heater nk
- Lsf heater nk b2
- Lsf sig
- Lsf signal nk b1
- Lsu comp
- Lsu ground vk b1
- Lsu heater
- Lsu pumping
- Pas control unit (behind left side of dash)
- Pdk control unit
- Pedal sens
- Power distribution system
- Pwg +5v 1
- Pwg +5v poti 2
- Quantity control valve
- Sensor ground
- Signal, maf
- Sports exhaust
- Starter lock
- Starter relay
- Starting/charging system
- Tailgate sw
- Tank leakage
- Tank leakage diagnostics module
- Terminal 15
- Terminal 30
- Terminal 31
- Terminal 87
3.8L, Электросхема системы управления двигателем (2 из 4) для Porsche 911 Carrera S 2009
3.8L, Электросхема системы управления двигателем (2 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (convertible) fuel pump control unit
- (left rear of engine compt) gp8
- (left side of support frame) gp3
- (side of expansion tank) cooling water level switch
- (w/ electronic fuel pump control unit) fuel pump level sensor
- Air cleaner
- Air conditioning system
- Camshaft adjustment 1 (cyl 1-3)
- Camshaft adjustment 2 (cyl 4-6)
- Clock sig h-
- Fuel level grd
- Fuel level sens
- Gnd
- Heated oxygen sensor catalytic converter bank 1
- Heated oxygen sensor catalytic converter bank 2
- Instrument cluster
- Knock sensor 1 (engine block)
- Knock sensor 2 (engine block)
- Mass air fuel sensor
- Measuring sig
- Nca
- Oil level sensor
- Pedal value sensor (behind accelerator pedal)
- Pump
- Pump +
- Pump -
- Pump current
- Pwm
- Resistor rt
- Sports exhaust system solenoid 1
- Sports exhaust system solenoid 2
- Tank venting valve
- Temp sens
- Term 15
- Terminal 31
- Terminal 87
- U battery h+
- Voltage re+
3.8L, Электросхема системы управления двигателем (3 из 4) для Porsche 911 Carrera S 2009
3.8L, Электросхема системы управления двигателем (3 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (relay support 1) (convertible) electric fuel pump relay 1
- (top of engine)
- Air bag control unit (below center console)
- Air cleaner
- Camshaft adjustment
- Camshaft sensor (left rear & right front of engine)
- Crash input
- Crash output
- Cylinder 1-
- Cylinder 3
- Cylinder 4
- Cylinder 5
- Cylinder 5-
- Dme control unit (left front of engine compt)
- Engine speed +
- Engine speed -
- Fuse f1 25a
- Fuses holder d
- Generator
- Gnd
- Hallgeber 1
- Hallgeber 2
- Hot at all times
- Lift valve control
- Nca
- Oil pressure
- Oil pressure resonance
- Resonance flap valve
- Shield
- System starting/charging
- Throttle valve
3.8L, Электросхема системы управления двигателем (4 из 4) для Porsche 911 Carrera S 2009
3.8L, Электросхема системы управления двигателем (4 из 4) для Porsche 911 Carrera S 2009 - Список элементов:
- (intake manifold) throttle valve
- (right side of engine) oil pressure sensor w/ temperature
- (top of cylinders)
- (top of cylinders) fuel injectors
- +5v
- Camshaft adjuster b1
- Camshaft b2
- Control valve
- Cooling water
- Cooling water sensor (in water box)
- Cylinder 1
- Cylinder 2
- Cylinder 6
- Dme control unit (left front of engine compt)
- Electronic mufflers system
- Engine compt
- Exhaust system
- Gp9 (right rear of engine compt)
- Ground, sensors
- High pressure rail sensor
- High pressure sens
- Ignition coil cylinder
- Injector, cylinder 1+
- Injector, cylinder 1-
- Injector, cylinder 2+
- Injector, cylinder 3+
- Injector, cylinder 3-
- Injector, cylinder 4+
- Injector, cylinder 4-
- Injector, cylinder 5+
- Injector, cylinder 6+
- Injector, cylinder 6-
- Nca
- Ntc
- Ntc engine compartment temperature sensor (middle of engine)
- Oil pressure sens
- Oil temp sens
- P-out
- Plug
- Resonance flap
- Sensor gnd
- Shield
- Sig
- Spark plug
- Tank valve
- Terminal 31
- Throttle valve
- Valve control b1
- Valve control b2
