Электросхемы ПРИВОД ЗЕРКАЛ Dodge Journey Crew 2010

ПРИВОД ЗЕРКАЛ

Электросхема автозатемнения зеркала заднего вида для Dodge Journey Crew 2010

Электросхема автозатемнения зеркала заднего вида для Dodge Journey Crew 2010 - Список элементов:

• Backup lamp relay (on pcb)
• Backup lamp sw fd
• Bkup lmps fd
• C114
• C201
• C201 b
• C212
• Circuit board
• Exterior lights system
• F943
• Fuse m15 20a
• Fuse m31 20a
• G200 (right end of dash)
• Gnd
• Hands free mic in +
• Hands free mic in -
• Hf mic 2 in +
• Hf mic hsd fd
• Hf mic ref
• Hot at all times
• Hot w/ run/start relay energized
• Ign rs
• Inside rearview mirror
• Radio
• S213
• S220
• S223
• Totally integrated power module (left rear of engine compt)
• X712
• X722
• X792
• X793
• X835
• Z906

Электросхема привода зеркал для Dodge Journey Crew 2010

Электросхема привода зеркал для Dodge Journey Crew 2010 - Список элементов:

• A16
• C112
• C113
• C300
• C302
• Circuit breaker 1 25a
• D a4
• Driver outside rearview mirror
• Driver window/door lock switch
• Drv pass
• Drv pass heated mrr fd
• Drv pwr
• Drv pwr mrr mtr horz
• Drv pwr mrr mtr vert
• Fuse m26 10a
• Fuse m35 10a
• G304 (under driver's seat)
• G305 (under front passenger's seat)
• Gnd
• Heated mrr fd
• Hot at all times
• Hot w/ rear window defogger relay energized
• Hot w/ run/accessory relay energized
• Mrr mtr horz
• Mrr mtr vert
• Mtr com
• Pass pwr
• Pass pwr mrr mtr horz
• Pass pwr mrr mtr vert
• Passenger outside rearview mirror
• Pwr mrr
• Pwr mrr mtr comm
• S328
• S330
• S508
• S523
• Sw 5v pwr mrr batt fd
• Totally integrated power module (left rear of engine compt)
• Wdw run/accy ign
