EXTERIOR LIGHTS – Ford Ranger 1998 – SYSTEM WIRING DIAGRAMS

EXTERIOR LIGHTS

Backup Lamps Wiring Diagram for Ford Ranger 1998

List of elements for Backup Lamps Wiring Diagram for Ford Ranger 1998:

• (rear lamp connector harn, under left rear of vehicle, near rear of frame)
• A/t
• Backup lamp switch (left side of transmission)
• Digital transmission range (dtr) sensor (rear left side of transmission)
• Fuse 15a
• G200 (behind left kick panel)
• Hot in run
• I/p fuse panel (behind left side of dash)
• Left backup lamp
• M/t
• Right backup lamp
• S126
• S400
• S403

Exterior Lamps Wiring Diagram for Ford Ranger 1998

List of elements for Exterior Lamps Wiring Diagram for Ford Ranger 1998:

• (dash panel to hdlmp junction harn, near breakout to left front park/turn lamp)
• (dash panel to hdlmp junction harn, near breakout to right front park/turn lamp)
• (dash panel to headlamp junction harn, near breakout to high pitch horn)
• (main harn, in breakout to transmission ctrl switch) s251
• (top center of left fender apron) g104
• Brake pedal position switch (on brake pedal support)
• C214
• C215
• C221
• C253
• C409
• Engine compartment fuse/relay box (left rear of engine compt)
• Exterior lights (trailer/camper adapter circuit) (i/p fuse panel, fuses 3 & 7)
• Exterior lights (trailer/camper adapter circuit) (parklamps trlr tow relay)
• Flasher (behind left side of dash, on i/p fuse panel)
• Fuse 15a
• Fuse 20a
• Fuse 7.5a
• G104 (top center of left fender apron)
• G105 (right side of engine compartment, on upper fender apron)
• G200 (behind left kick panel)
• Generic electronic module (gem)/ central timer module (ctm) (behind center of dash)
• Ground
• Hazard
• Hazard sw out
• Head
• Hot at all times
• Hot in run
• I/p fuse panel (behind left side of dash)
• Ignition
• Instrument cluster
• Instrument illumination dimming module (top left side of dash)
• Left front park/ turn lamp
• Left front side marker lamp
• Left license lamp
• Left rear park/ stop lamp
• Left rear turn lamp
• Left turn
• Left turn indicator
• Main light switch
• Multi-function switch (top left side of steering column)
• Normal
• Off
• Outside cargo/ high mount stop lamp
• Park
• Park lamps relay
• Power
• Relay box 1 (behind dash, right of steering column)
• Remote anti- theft personality (rap) module (left rear corner of cab)
• Right front park/ turn lamp
• Right front side marker lamp
• Right license lamp
• Right rear park/ stop lamp
• Right rear turn lamp
• Right turn
• Right turn indicator
• S130
• S154
• S155
• S214
• S234 (main harn, near breakout to i/p fuse panel)
• S252 (main harn, in breakout to transmission ctrl switch)
• S300
• S307
• S400
• S401 (rear lamp harn)
• S402 (rear lamp harn)
• S407 (rear lamp harn, near breakout to license lamps)
• Turn signal sw
• W/ anti- theft
• W/o anti- theft
• W/o anti-theft

Trailer/Camper Adapter Wiring Diagram for Ford Ranger 1998

List of elements for Trailer/Camper Adapter Wiring Diagram for Ford Ranger 1998:

• Exterior lights (main light switch or park lamp relay)
• Fuse 15a
• Fuse 7.5a
• G104 (top center of left fender apron)
• G200 (behind left kick panel)
• Hot at all times
• I/p fuse panel (behind left side of dash)
• Multi- function switch
• Park lamp/ trailer tow relay (in engine compartment fuse/relay panel)
• Right turn/ stop sig
• S131
• S307
• Stop lamp)
• Trailer/ camper adapter (ground)
• Trailer/ camper adapter (left turn/ stop lamp)
• Trailer/ camper adapter (right turn/
• Trailer/ camper adapter (running lamps)
