POWER WINDOWS

Power Window Wiring Diagram for Ford Ranger 1998

List of elements for Power Window Wiring Diagram for Ford Ranger 1998:

• 87a
• Acc delay rly
• Accessory delay relay (under right side of dash)
• Batt savr ctrl
• Battery saver relay
• C224
• Down
• Down comnd in
• Down sense(hi)
• Down sense(lo)
• Engine compartment fuse/relay box (left rear of engine compt)
• Fuse 10a
• G200 (behind left kick panel)
• Generic electronic module (behind center of dash)
• Hot at all times
• I/p fuse panel (behind left side of dash)
• Interior lights system
• Left
• Left power window motor
• Master window control switch
• One touch down relay module
• Otd relay out
• Power lock/ window/seat maxi fuse 4 20a
• Red
• Relay box 1 (behind dash, right of steering column)
• Right
• Right power window motor
• Right window switch
• S203 (main harn, near breakout to 3 pin conn, behind right side of dash)
• S210 (main harn, near breakout to rear of radio)
• S217 (main harn, near breakout to rear of radio)
• S221 (main harn, near breakout to i/p fuse panel)
• S226 (main harn, near breakout to generic electronic module)
• S500
• Transmissions system
