POWER DISTRIBUTION – Ford Ranger 1998 – SYSTEM WIRING DIAGRAMS

POWER DISTRIBUTION

Power Distribution Wiring Diagram (1 of 3) for Ford Ranger 1998

List of elements for Power Distribution Wiring Diagram (1 of 3) for Ford Ranger 1998:

• (bottom of steering column) s218
• (not used)
• 4wabs control module
• A/c clutch control relay
• Accessory delay relay
• Air bag electronic crash sensor
• Battery
• Blower motor relay
• C111
• Daytime running lamps
• Daytime running lamps module
• Electric shift control module
• Electric shift relay
• Engine compartment fuse/relay box (left rear of engine compartment)
• Fog lamp relay
• From c fuse 3 (diagram 1 of 3)
• From fuse 11 (diagram 1 of 3)
• Fuel pump relay
• Fuse 10a
• Fuse 15a
• Fuse 20a
• Fuse 30a
• Generator/ voltage regulator
• Horn relay
• Main light switch
• Maxi fuse 20a
• Maxi fuse 40a
• Maxi fuse 50a
• Mega fuse 175a
• Multi- function switch
• Nca
• Park lamps relay
• Pcm power relay
• Red
• Relay box (right side of steering column)
• Remote anti-theft personality module
• S116 (dash panel to headlight jct harn, left rear of engine compartment)
• S153 (dash panel to headlight jct harn, near breakout to eng compt fuse/relay box)
• S230
• Starter motor
• Starter motor relay
• To fuse 6 (diagram 1 of 3)
• To fuse 7 (diagram 1 of 3)
• To i/p fuse panel fuse 5 (diagram 2 of 3)
• To s232 (diagram 2 of 3)
• W/ power equipment
• W/o power equipment

Power Distribution Wiring Diagram (2 of 3) for Ford Ranger 1998

List of elements for Power Distribution Wiring Diagram (2 of 3) for Ford Ranger 1998:

• (eng ctrl sens harn, right side of eng cmpt) s101
• (eng ctrl sens harn, top left of eng) s101
• (main harn, near ign switch)
• (not used)
• 2.5l engine
• 3.0l/ 4.0l engine
• Acc
• All lock relay
• All unlock relay
• Auxiliary power socket
• Battery saver relay
• Brake pedal position switch
• Brake pressure switch
• Cigar lighter
• Data link connector
• Driver's unlock relay
• Engine compartment fuse/relay box (left rear of engine compartment)
• Flasher
• From ignition switch i1 (diagram 2 of 3)
• From maxi fuse 1 (diagram 1 of 3)
• From maxi fuse 5 (diagram 1 of 3)
• Fuse 10a
• Fuse 15a
• Fuse 20a
• Fuse 25a
• Fuse 7.5
• Fuse 7.5a
• G104 top center of left fender apron)
• Generic electronic module/ central timer module
• I/p fuse panel (left side of dash)
• Ignition coil
• Ignition switch
• Instrument cluster
• Lock
• Lock off
• Main light switch
• Off
• Park lamp/ trailer tow relay
• Pcm power diod
• Pcm power relay
• Power mirror switch
• Primary coil
• Rabs resistor
• Rabs test connector
• Radio
• Radio noise capacitor
• Red
• Relay box (right side of steering column)
• Run
• S201
• S232
• Secondary coil
• Sta
• Start
• To fuse 11 (diagram 2 of 3)
• To fuse 16 (diagram 3 of 3)
• To fuse 2 (diagram 3 of 3)
• To fuse 24 (diagram 3 of 3)
• To fuse 27 (diagram 3 of 3)

Power Distribution Wiring Diagram (3 of 3) for Ford Ranger 1998

List of elements for Power Distribution Wiring Diagram (3 of 3) for Ford Ranger 1998:

• (dash panel to headlamp jct harn, left side of firewall) s138
• (dash panel to headlight junction harn, left front of vehicle) s126
• (main harn, near breakout to i/p fuse panel) s250
• (main harn, near breakout to instrument cluster) s227
• 4wheel anti-lock brake system module
• A/c heater control assembly
• A/t
• Air bag electronic crash sensor
• Backup lamp switch
• Blend door actuator
• Blower motor relay
• Clutch pedal position switch
• Daytime running lamps module
• Digital transmission range sensor
• Engine compartment fuse/relay box (left rear of engine compartment)
• Flasher
• From ignition switch a1 (diagram 2 of 3)
• From ignition switch a2 (diagram 2 of 3)
• From ignition switch a4 (diagram 2 of 3)
• From ignition switch sta (diagram 2 of 3)
• Fuse 10a (4wabs)
• Fuse 15a
• Fuse 20a (rabs)
• Fuse 30a
• Fuse 7.5a
• Fuse 7.5a (w/ rap)
• Fuse 7.5a (w/o rap)
• Generic electronic module
• Generic electronic/ central timer module
• I/p fuse panel (left side of dash)
• M/t
• Nca
• Passive deactivation module
• Pulse vacuum hublock solenoid switch
• Radio
• Rear anti-lock brakes system module
• Red
• Relay box (right side of steering column)
• Remote anti-theft personality module
• S1002
• Shift lock actuator
• Speed control servo amplifier assembly
• Starter interrupt relay
• Transmission control switch
• W/ anti-theft
• W/o anti-theft
• Washer pump relay
• Windshield wiper motor
• Wiper hi/lo relay
• Wiper run/ park relay
