ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема предупреждающей системы для Dodge Sprinter 3500 2005

Электросхема предупреждающей системы для Dodge Sprinter 3500 2005 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема предупреждающей системы для Dodge Sprinter 3500 2005 - Список элементов:

  • (left rear of engine compt)
  • (under dash) data link connector
  • (under left side of dash) ambient temperature sensor
  • Air bag control module (under driver's seat)
  • Air bag warning ind
  • Air conditioning system
  • Ambient temp sens sig (+)
  • Ambient temp sens sig ret
  • Brake fluid level ind sig
  • Brake fluid level switch (on master cylinder)
  • Brake wear sensor sig
  • Can c bus (+)
  • Can c bus (-)
  • Computer data lines system
  • D+ relay 1 control
  • Driver door jamb switch
  • Eng cool level sw sig
  • Engine coolant level switch (front of eng compt)
  • Exterior lights system
  • Frt crtsy lps cntrl
  • Fuel level sens sig (+)
  • Fuel level sens sig ret
  • Fuel level sensor (top of fuel tank)
  • Fuse 15a
  • Fuse 7.5a
  • Fuse block 1 (under steering column)
  • Fuse block 2 (under driver's seat)
  • Fused b(+)
  • Fused hi beam sel sw out
  • Fused ign sw (run/start)
  • G100 (left front of engine compt)
  • G200
  • G200 (left rear of engine compt)
  • G202 (under driver's seat)
  • G203 (behind left side of dash)
  • G300 (rear of vehicle)
  • Gen field driver
  • Generator
  • Ground
  • Headlights system
  • Hot at all times
  • Hot in run or start
  • Ignition lock switch
  • Instrument cluster
  • Instrument panel socket
  • Interior lights system
  • K-ic/atc/hbm/chm
  • Key-in ign sw signal
  • Lamp driver
  • Left front brake wear sensor
  • Left rear brake wear sensor
  • Left turn signal
  • Nca
  • Park brake ind sig
  • Parking brake switch (under dash)
  • Passenger door jamb switch
  • Radio
  • Red
  • Right front brake wear sensor
  • Right rear brake wear sensor
  • Right turn signal
  • S200
  • S221 (near data link connector)
  • S228 (behind dash)
  • S230
  • S261
  • S322 (behind dash)
  • S323 (near left rear brake pad sensor)
  • S326 (near front center of roof)
  • S332
  • Seat belt sw sig
  • Seat belt switch (driver's seat belt lock)
  • Vss out
  • Vss output
