Электросхемы СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS Dodge Sprinter 3500 2005

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS) для Dodge Sprinter 3500 2005

Электросхема антиблокировочной тормозной системы АБС (ABS) для Dodge Sprinter 3500 2005 - Список элементов:

• (left front of engine compt) g100
• (left front of engine compt) g302
• (near right rear wheel speed sensor)
• (not used)
• Additional heat exchanger switch
• Automatic temperature control module
• Auxiliary heater timer
• Brake lamp sw out
• Brake lamp switch (on brake pedal support)
• Brake pressure sensor (in air intake duct)
• Brake sw out
• Brk press sens
• Can c +
• Can c -
• Can c bus (+)
• Can c bus (-)
• Computer data lines system
• Controller anti-lock brake (left side of engine compt)
• Data link connector (under dash)
• Fuse 10a
• Fuse 25a
• Fuse 40a
• Fuse 7.5a
• Fuse block 1 (under steering column)
• Fuse/relay block (under driver's seat)
• Fused b (+)
• Fused ign sw output
• Fused ign sw output c1
• Fused relay out
• G200 (left rear of engine compt)
• Grd
• Hot at all times
• Hot in run or start
• Hot w/ optional equipment relay energized
• Instrument cluster
• Interior lights system
• K-abs/shifter assy
• Lateral acceleration sensor (under driver's seat)
• Left front wheel speed sensor
• Left rear wheel speed sensor
• Lf whl spd sens +
• Lf whl spd sens -
• Lr whl spd sens +
• Lr whl spd sens -
• Power input
• Red
• Rf whl spd sens +
• Rf whl spd sens -
• Right front wheel speed sensor
• Right rear wheel speed sensor
• Rr whl spd sens +
• Rr whl spd sens -
• S201 (behind center of dash)
• S204
• S229 (left side of engine compt)
• S251 (left side of eng compt)
• S307
• S312
• S313
• S314
• S315
• Sensor grd
• Sensor sig
• Steering angle sensor
• Tcs sw (asr) sens
• Tcs switch (asr)
