ПРИВОД СТЕКЛОПОДЪЕМНИКОВ

Электросхема стеклоподъемников для Audi A3 Quattro 2009

Электросхема стеклоподъемников для Audi A3 Quattro 2009 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема стеклоподъемников для Audi A3 Quattro 2009 - Список элементов:

  • (behind left kick panel) g44
  • (behind right kick panel) g638
  • 12a
  • 13a
  • 23a
  • 28a
  • 38a
  • Central window regulator switch
  • Computer data lines system
  • Driver's door control module (integrated in driver's door window regulator motor)
  • Driver's door power window master switch
  • Driver's window regulator motor
  • Front passenger window regulator motor
  • Front passenger's door control module (integrated in right front door window regulator motor)
  • Fuse 10a
  • Fuse 30a
  • Fuse panel sc
  • G638 (behind right kick panel)
  • Hot at all times
  • Interior lights system
  • Left front window regulator switch
  • Left rear door control module (integrated in left rear door window regulator motor)
  • Left rear door window switch
  • Left rear window regulator motor
  • Left rear window regulator switch
  • Passenger door window regulator switch
  • Right front window regulator switch
  • Right rear door control module (integrated in right rear door window regulator motor)
  • Right rear door window switch
  • Right rear window regulator motor
  • Right rear window regulator switch
  • T20f
  • T20g
  • T20n
  • T20o
  • T32a
  • T32b
  • T32e
  • T32f
  • W/ passenger compartment monitoring
  • W/o passenger compartment monitoring
